Hardware support and maintenance Nutanix HPE Proliant



The Nutanix hardware you have in your IT infrastructure can still provide the functionality, flexibility and practicality for the vast majority of organizations today. The ability to add additional memory (if not already specified at time of purchase) and CPU provides customers with a variety of options to upgrade their host servers (virtualized environments) to continue to deliver the required performance beyond the manufacturers' end-of-life dates. These potential upgrade options mean that customers do not have to constantly look for new server solutions at the end of a 3 or 5 year internal lifecycle program because the servers are no longer fit for purpose.



Nutanix hardware from partners

Outsourcing Nutanix Hardware Maintenance



DC Parts provides organizations with a viable and sustainable alternative option to extend the life of their Nutanix hardware after 'end of life' or 'end of life support' announcements and is able to provide recommended hardware upgrade options , which includes and incorporates complete installation and configuration work performed by experienced technical field engineers. Our ability to continue to provide an alternative server maintenance support service for Nutanix haedware further assists organizations by providing a cost-effective solution for mission-critical Nutanix hardware. This solution significantly reduces your total cost of ownership and also generates a greater return on your initial capital expenditure on IT server hardware.

DC Parts offers a flexible approach for organizations looking to partially or fully integrate with their organization's maintenance and support services for current or historical server systems. These service levels range from NBD (Next Business Day) to a 24/7 response. Our maintenance and support services range from parts only to telephone and remote support. Our service level pages describe these and other services in detail.

Sign in contact with us to see if we can provide the guarantees you need, especially to explore an alternative maintenance support service.

Asset Residual Value for Your Nutanix Hardware



Our exclusive maintenance and support service for Nutanix hardware can provide you with the potential to customize a cost-neutral maintenance contract for Nutanix hardware that is now post-warranty, end of life or end of life (EOL / EOSL). Our service allows customers with Nutanix hardware to have multiple stages in a lifecycle program, while providing extended maintenance support regardless of the need for 3,6,9 or even 12 months of support, thus effectively creating a solution neutral in terms of cost.



Cost reduction in your contract



We allow a cost neutral maintenance solution to be provided through the residual value on your Nutanix hardware that we would remove at the end of the agreed maintenance support term. As well as services for secure deactivation and elimination of data according to internal compliance requirements will also be part of the discussion of the hardware lifecycle services program.

If you don't need a support service, our maintenance service can still benefit you. So we can provide a residual value quote for your IT server and storage hardware and discuss the process of deactivating and deleting data, allowing you to get a much higher return on your initial capital investment. There is no obligation to obtain a quote from DC Parts, but it does allow you to explore whether this service can be viable and beneficial for you.

Hyper-converged infrastructure (HCI) is becoming a significant service platform in the datacenter, and with good reason. Processing abstraction, storage and network resources to create a fully software-defined network datacenter is the logical progression of the decade of virtualization trend. Companies like Nutanix are leading the way, enabling IT departments to create and expand application environments by simply adding common off-the-shelf servers. Eliminating the expense and complexity of deploying and managing a datacenter full of disparate devices with a mix of management interfaces plus multiple networking and storage protocols make it easier to deploy and support an on-premises cloud.

As one of the leading enterprise server vendors, the HPE product line is a recognized standard when it comes to datacenter deployments. The Proliant platform is an ideal building block for a Nutanix private cloud. HPE's partnership with Nutanix extends to Proliant series appliances – one and two rack unit Proleiant servers specifically certified to support the Nutanix HCI solution.

DC Parts has extensive knowledge of HPE Proliant hardware and our team has years of experience with Proliant systems. DC Parts can customize a support package to meet your organization's immediate or long-term needs, from short-term 9-5 contracts to 24/7 annual maintenance packages. DC Parts consultants work with clients to ensure they get the assurance they need at a cost that fits their budget. Our flexibility, along with our comprehensive understanding of the PowerEdge line, allows DC Parts to help organizations maximize their IT infrastructure investment.



Benefits of maintenance support DC Parts in hardware Nutanix com HPE Proliant



  • Technical diagnostics and repair of Dell PowerEdge servers
  • Level 3 engineer assigned to an account
  • Global service availability
  • Maintenance support for current and end-of-life Dell equipment
  • Pro-rata support and co-termination dates
  • Site audits / surveys
  • Data / platform migration
  • IT decommissioning
  • Data erasure
  • Highly experienced and specially trained technical field engineers
  • On-site spare parts cache
  • Various methods for generating a fault ticket ticket
  • Helpdesk assistance
  • Operating system and firmware recommendations
  • Professional services
    • CONSULTANCY
    • VMware
    • Hardware upgrades
  • Flexible short and long-term maintenance support contracts
  • Hardware rental
  • DMR (digital media retention)
  • Operational savings



End of support Nutanix with hardware HPE Proliant, but not DC Parts



Supported Models

Hardware Supported Models
HPE® Gen10 Servers
  • HPE® ProLiant® Servers
    • DL360 Gen10 8SFF Hardware Compatibility
    • DL380 Gen10 12LFF Hardware Compatibility
    • DL380 Gen10 24SFF Hardware Compatibility
  • HPE® Apollo® System
    • Apollo® R2600 XL170r Gen10 24SFF Hardware Compatibility
HPE® Gen9 Servers
  • HPE® ProLiant® Servers
    • DL360 Gen9 8SFF Hardware Compatibility
    • DL380 Gen9 8SFF Hardware Compatibility
    • DL380 Gen9 12LFF Hardware Compatibility
    • DL380 Gen9 24SFF Hardware Compatibility

DL360 Gen10 8SFF Hardware Compatibility



Qualification date: January 2018



Component Description SKU
Chassis 1 RU server, 8 x 2.5″ SFF drives



Use cases:

  • Analytics and Big Data
  • End-User Computing / Virtual Desktop Infrastructure
HPE ProLiant DL360 Gen10 8SFF NC CTO Server

Nodes per chassis: 1

P19766-B21
HPE ProLiant DL360 Gen10 8SFF NC TAA-Compliant CTO Server

Nodes per chassis: 1

P19769-B21
HPE ProLiant DL360 Gen10 8SFF Configure-To-Order Base Server

Nodes per chassis: 1

867959-B21
HPE ProLiant DL360 Gen10 TAA-compliant 8SFF Configure-To-Order Server

Nodes per chassis: 1

875966-B21
boot drive 1 x M.2 SSD

150GB HPE SATA 6G RI M.2 Digitally Signed Firmware SSD 875317-B21  (EOS)
240 GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD 875488-B21  (EOS)
HPE 480GB SATA RI M.2 2280 SSD P19890-B21
Power Supply 2 x Hot-plug power supply
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit 865408-B21
HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit 865414-B21
HPE iLO License HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features 512485-B21



Table. storage
Component Description SKU
Storage: All-Flash Only SATA/SAS SSDs
2, 4, 6, or 8 x 2.5″ SATA/SAS SSDs

480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873363-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872376-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04527-B21
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09716-B21
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05980-B21
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873365-B21  (EOS)
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872382-B21  (EOS)
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04533-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09092-B21
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 877788-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05986-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04566-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05938-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06588-B21  (EOS)
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04570-B21
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04521-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05946-B21
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06590-B21  (EOS)
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD P19909-B21
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
2 x 2.5″ SATA/SAS SSDs

480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873363-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872376-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04527-B21
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09716-B21
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05980-B21
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873365-B21  (EOS)
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872382-B21  (EOS)
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04533-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09092-B21
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 877788-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05986-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04566-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05938-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06588-B21  (EOS)
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04570-B21
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04521-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05946-B21
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06590-B21  (EOS)
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD P19909-B21
4 or 6 x 2.5″ HDDs
1TB HPE 2.5 inch 12Gbps SAS 7.2K RPM SFF SC HDD 832514-B21  (EOS)
HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD 765466-B21
HPE 2.4TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD 881457-B21
Storage Controller 1 x HPE Smart Array E208i-a SR Gen10 (8 Internal Lanes/No Cache) 12G SAS Modular Controller 804326-B21



Table. Skylake: CPU and Memory
Component Description SKU
CPU 1 or 2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU). Various
Memory
DDR4-2666, 1.2V, 16GB, RDIMM

  • 6 x 16 GB = 96 GB
  • 8 x 16 GB = 128 GB
  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
835955-B21
DDR4-2666, 1.2V, 32GB, RDIMM

  • 6 x 32 GB = 192 GB
  • 8 x 32 GB = 256 GB
  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
815100-B21
DDR4-2666, 1.2V, 64GB, LRDIMM

  • 6 x 64 GB = 384 GB
  • 8 x 64 GB = 512 GB
  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
815101-B21
DDR4-2666, 1.2V, 128GB, LRDIMM

  • 6 x 128 GB = 768 GB
  • 8 x 128 GB = 1 TB
  • 12 x 128 GB = 1.5 TB
  • 16 x 128 GB = 2 TB
  • 24 x 128 GB = 3 TB
815102-B21



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 x LAN on Motherboard (LOM) Adapter
HPE Ethernet 1Gb 4-port 366FLR Adapter 665240-B21
HPE Ethernet 10GbE 2-port 562FLR-SFP+ Adapter 727054-B21
HPE Ethernet 10Gb 2-port 562FLR-T Adapter 817745-B21
HPE Ethernet 10/25Gb 2-port 640FLR-SFP28 Adapter 817749-B21
PCIe Network Interface 1 or 2 x PCIe-slot Ethernet adapter
HPE Ethernet 10Gb 2-port 562SFP + Adapter 727055-B21
HPE Ethernet 1Gb 4-port 366T Adapter 811546-B21
HPE Ethernet 10Gb 2-port 562T Adapter 817738-B21
HPE Ethernet 10/25Gb 2-port 640SFP28 Adapter 817753-B21
Dual NIC Configuration

DL380 Gen10 12LFF Hardware Compatibility



Qualification date: January 2018



Component Description SKU
Chassis 2 RU server, 12 x 3.5″ LFF drives, 2 x 2.5″ SFF drivesUse cases:

  • Analytics and Big Data
  • Backup and Disaster Recovery
  • Files and Objects
  • Private Cloud
  • Test and Development
  • End-User Computing / Virtual Desktop Infrastructure
HPE ProLiant DL380 Gen10 12LFF NC CTO Server

Nodes per chassis: 1

P19718-B21
HPE ProLiant DL380 Gen10 12LFF Configure-To-Order Server

Nodes per chassis: 1

868705-B21
HPE ProLiant DL380 Gen10 TAA-compliant 12LFF Configure-To-Order Server

Nodes per chassis: 1

875785-B21
boot drive 1 x M.2 SSD

150GB HPE SATA 6G RI M.2 Digitally Signed Firmware SSD 875317-B21  (EOS)
240 GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD 875488-B21  (EOS)
HPE 480GB SATA RI M.2 2280 SSD P19890-B21
Power Supply 2 x Hot-plug power supply
HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit 830272-B21
HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit 865414-B21
HPE iLO License HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features 512485-B21



Table. storage
Component Description SKU
Storage: All-Flash Only SATA/SAS SSDs
4, 6, 8, 10, 12, or 14 x 2.5″ and 3.5″ SATA/SAS SSDs (upto 12 LFF + 0 or 2 SFF)

480GB HPE Hot-swappable (3.5in) SATA 6Gbps MU LFF SCC DS SSD 872346-B21  (EOS)
480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
800GB HPE SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD (Extended) 872378-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872376-B21  (EOS)
HPE 800GB SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD P04529-B21
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable (3.5in) SATA 6Gbps MU LFF SCC DS SSD 872350-B21  (EOS)
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD P09718-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04533-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09092-B21
HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD P09724-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04570-B21
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06588-B21  (EOS)
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04521-B21
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
2 or 4 x 2.5″ and 3.5″ SATA/SAS SSDs

480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
480GB HPE Hot-swappable (3.5in) SATA 6Gbps MU LFF SCC DS SSD 872346-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873363-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872376-B21  (EOS)
800GB HPE SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD (Extended) 872378-B21  (EOS)
HPE 800GB SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD P04529-B21
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
960GB HPE Hot-swappable (3.5in) SATA 6Gbps MU LFF SCC DS SSD 872350-B21  (EOS)
HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD P09718-B21
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05980-B21
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873365-B21  (EOS)
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872382-B21  (EOS)
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04533-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09092-B21
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD P09724-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04570-B21
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06588-B21  (EOS)
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04521-B21
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06590-B21  (EOS)
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04523-B21
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD P19909-B21
4, 6, 8, 10, or 12 x 3.5″ HDDs

1TB HPE 3.5″ 12Gbps SAS 7.2K RPM LFF SC HDD 846524-B21  (EOS)
HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD 872485-B21
4TB HPE 3.5″ 12Gbps Midline SAS 7.2K RPM LFF SC DS HDD 872487-B21
6TB HPE 3.5″ 12Gbps Midline SAS 7.2K RPM LFF SC DS HDD 846514-B21  (EOS)
8TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

819201-B21
HPE 12TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD 881779-B21
Storage Controller 1 x Storage Controller
HPE Smart Array E208i-a SR Gen10 (8 Internal Lanes/No Cache) 12G SAS Modular Controller 804326-B21
HPE DL38X Gen10 2SFF Premium HDD Front NVMe or Front / Rear SAS / SATA Kit

826687-B21
Storage Expander Card 1 x HPE DL38X Gen10 12Gb SAS Expander Card Kit with Cables 870549-B21



Table. Skylake: CPU and Memory
Component Description SKU
CPU 2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU). Various
Memory
DDR4-2666, 1.2V, 16GB, RDIMM

  • 8 x 16 GB = 128 GB
  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
835955-B21
DDR4-2666, 1.2V, 32GB, RDIMM

  • 8 x 32 GB = 256 GB
  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
815100-B21
DDR4-2666, 1.2V, 64GB, LRDIMM

  • 8 x 64 GB = 512 GB
  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
815101-B21
DDR4-2666, 1.2V, 128GB, LRDIMM

  • 8 x 128 GB = 1 TB
  • 12 x 128 GB = 1.5 TB
  • 16 x 128 GB = 2 TB
  • 24 x 128 GB = 3 TB
815102-B21



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 x LAN on Motherboard (LOM) Adapter
HPE Ethernet 1Gb 4-port 366FLR Adapter 665240-B21
HPE Ethernet 10GbE 2-port 562FLR-SFP+ Adapter 727054-B21
HPE Ethernet 10Gb 2-port 562FLR-T Adapter 817745-B21
HPE Ethernet 10/25Gb 2-port 640FLR-SFP28 Adapter 817749-B21
PCIe Network Interface 1 or 2 x PCIe-slot Ethernet adapter
HPE Ethernet 10Gb 2-port 562SFP + Adapter 727055-B21
HPE Ethernet 1Gb 4-port 366T Adapter 811546-B21
HPE Ethernet 10Gb 2-port 562T Adapter 817738-B21
HPE Ethernet 10/25Gb 2-port 640SFP28 Adapter 817753-B21
Dual NIC Configuration

DL380 Gen10 24SFF Hardware Compatibility



Qualification date: January 2018



Component Description SKU
Chassis 2 RU server, 24 x 2.5″ SFF drives



Use cases:

  • Analytics and Big Data
  • Database and Business Critical Apps
  • Private Cloud
  • Test and Development
  • End-User Computing / Virtual Desktop Infrastructure
HPE ProLiant DL380 Gen10 24SFF NC CTO Server

Nodes per chassis: 1

P19719-B21
HPE ProLiant DL380 Gen10 24SFF Configure-To-Order Server

Nodes per chassis: 1

868704-B21
HPE ProLiant DL380 Gen10 TAA-compliant 24SFF Configure-To-Order Server

Nodes per chassis: 1

875783-B21
boot drive 1 x M.2 SSD

150GB HPE SATA 6G RI M.2 Digitally Signed Firmware SSD 875317-B21  (EOS)
240 GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD 875488-B21  (EOS)
HPE 480GB SATA RI M.2 2280 SSD P19890-B21
Power Supply 2 x Hot-plug power supply
HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit 830272-B21
HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit 865414-B21
HPE iLO License HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features 512485-B21



Table. storage
Component Description SKU
Storage: All-Flash Only SATA/SAS SSDs
8, 10, 12, 14, 16, 18, 20, 22, 24, or 26 x 2.5″ SATA/SAS SSDs

480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873363-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872376-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04527-B21
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09716-B21
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05980-B21
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873365-B21  (EOS)
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872382-B21  (EOS)
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04533-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09092-B21
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 877788-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04566-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05986-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05938-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06588-B21  (EOS)
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04570-B21
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04521-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05946-B21
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06590-B21  (EOS)
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
4, 6, or 8 x 2.5″ SATA/SAS SSDs

480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873363-B21  (EOS)
800GB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872376-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04527-B21
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09716-B21
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05980-B21
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 873365-B21  (EOS)
1.6TB HPE SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 872382-B21  (EOS)
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04533-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09092-B21
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD 877788-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04566-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05986-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05938-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06588-B21  (EOS)
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04570-B21
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04521-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P05946-B21
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P06590-B21  (EOS)
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04523-B21
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD P19909-B21
8, 10, 12, 14, 16, 18, 20, or 22 x 2.5″ HDDs

1TB HPE 2.5 inch 12Gbps SAS 7.2K RPM SFF SC HDD 832514-B21  (EOS)
1.8TB HPE SAS 12G Enterprise 10K SFF (2.5in) SC 512e Digitally Signed Firmware HDD 872481-B21
HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD 765466-B21
HPE 2.4TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD 881457-B21
Storage Controller 1 x Storage Controller
HPE Smart Array E208i-a SR Gen10 (8 Internal Lanes/No Cache) 12G SAS Modular Controller 804326-B21
HPE DL38X Gen10 2SFF Premium HDD Front NVMe or Front / Rear SAS / SATA Kit

826687-B21
storage expander card 1 x HPE DL38X Gen10 12Gb SAS Expander Card Kit with Cables 870549-B21



Table. Skylake: CPU and Memory
Component Description SKU
CPU 2 x Intel Skylake Silver CPU, minimum 6 cores or higher.

Various
Memory
DDR4-2666, 1.2V, 16GB, RDIMM

  • 8 x 16 GB = 128 GB
  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
835955-B21
DDR4-2666, 1.2V, 32GB, RDIMM

  • 8 x 32 GB = 256 GB
  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
815100-B21
DDR4-2666, 1.2V, 64GB, LRDIMM

  • 8 x 64 GB = 512 GB
  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
815101-B21
DDR4-2666, 1.2V, 128GB, LRDIMM

  • 8 x 128 GB = 1 TB
  • 12 x 128 GB = 1.5 TB
  • 16 x 128 GB = 2 TB
  • 24 x 128 GB = 3 TB
815102-B21



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 x LAN on Motherboard (LOM) Adapter
HPE Ethernet 1Gb 4-port 366FLR Adapter 665240-B21
HPE Ethernet 10GbE 2-port 562FLR-SFP+ Adapter 727054-B21
HPE Ethernet 10Gb 2-port 562FLR-T Adapter 817745-B21
HPE Ethernet 10/25Gb 2-port 640FLR-SFP28 Adapter 817749-B21
PCIe Network Interface 1 or 2 x PCIe-slot Ethernet adapter
HPE Ethernet 10Gb 2-port 562SFP + Adapter 727055-B21
HPE Ethernet 1Gb 4-port 366T Adapter 811546-B21
HPE Ethernet 10Gb 2-port 562T Adapter 817738-B21
HPE Ethernet 10/25Gb 2-port 640SFP28 Adapter 817753-B21
Dual NIC Configuration



Table. But by the full GPU acceleration tech
Component Description SKU
HPE Computation and Graphics Accelerators 1 or 2 x GPU

HPE NVIDIA Tesla P40 24GB Module Q0V80A
NVIDIA Tesla M10 Quad GPU Module Q0J62A
HPE NVIDIA Tesla V100 PCIe 16GB Computational Accelerator Q2N68A
HPE NVIDIA Tesla V100 PCIe 32GB Computational Accelerator Q9U36A
HPE NVIDIA Tesla T4 16GB Computational Accelerator R0W29A
Riser Kit Riser Kit
HPE DL Gen10 x16/x16 GPU Riser Kit 826704-B21
HPE DL38X Gen10 x16/x16 GPU Slot2/3 FIO Riser Kit 871676-B21
GPU Power Cable Kit GPU Power Cable Kit

HPE DL380 Gen10 8-pin Cable Kit 871828-B21
HPE DL380 Gen10 8-pin Keyed Cable Kit 871829-B21

Apollo® R2600 XL170r Gen10 24SFF Hardware Compatibility



Qualification date: February 2019



Component Description SKU
Chassis

Chassis and chassis sub-components

2 RU HPE Apollo r2600 24 SFF Chassis

Nodes per chassis: Up to 4

867158-B21
2 x HPE 1800W-2200W Flex Slot Platinum Hot Plug Power Supply Kit 876935-B21
1 x HPE r2x00 Gen10 1800-2200W Redundant Power Supply Enablement Kit 880189-B21
1 x HPE r2x00 Gen10 Redundant Fan Module Kit 874308-B21
Node 1, 2, 3, or 4 x nodes per chassis

1U Half-width ProLiant XL170r Gen10 server, 6-drive, SFF 867055-B21
HPE Legacy FIO Mode Setting, per node 758959-B22
boot drive 1 x M.2 SSD and Riser Kit, per node
240 GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD 875488-B21
HPE XL1x0r Gen10 M2 (NGFF) Riser Kit 874853-B21
HPE iLO License 1 x HPE iLO Advanced with 1-year 24 × 7 Technical Support Single-Server License

512485-B21



Table. storage
Component Description SKU
Storage: All-flash

Only SSDs

2, 4, or 6 x 2.5″ SSDs, per node
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09716-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04570-B21
Storage: Hybrid

Mix of SSDs and HDDs

2 x 2.5″ SSDs, per node
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09716-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P04570-B21
4 x 2.5″ HDDs, per node
1TB HPE 2.5″ 12Gbps SAS 7.2K RPM SFF SC HDD 832514-B21
2TB HPE 2.5″ 12Gbps Midline SAS 7.2K RPM SFF SC 512e DS HDD 765466-B21
Storage Controller 1 x Storage Controller, Cable Kit, and Riser Kit, per node.
HPE Smart Array E208i-p SR Gen10 (8 Internal Lanes/No Cache) 12G SAS PCIe Plug-in Controller 804394-B21
HPE XL1x0r Gen10 Left Low Profile Riser Kit 874296-B21
HPE XL170r Left E208ip/P408ip Cable Kit 874785-B21



Table. Skylake: CPU and Memory
Component Description SKU
CPU 2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU). Various
Memory
DDR4-2666, 1.2V, 16GB, RDIMM

  • 12 x 16 GB = 192 GB
835955-B21
DDR4-2666, 1.2V, 32GB, RDIMM

  • 12 x 32 GB = 384 GB
815100-B21
DDR4-2666, 1.2V, 64GB, LRDIMM

  • 12 x 64 GB = 768 GB
815101-B21
DDR4-2666, 1.2V, 128GB, LRDIMM

  • 12 x 128 GB = 1.5 TB
815102-B21



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 x LAN on Motherboard (LOM) Adapter and Riser Kit, per node.
HPE Ethernet 10Gb 2-port 562FLR-T Adapter 817745-B21
HPE Ethernet 10/25Gb 2-port 640FLR-SFP28 Adapter 817749-B21
HPE XL170r Gen10 FlexibleLOM Riser Kit 874298-B21

DL360 Gen9 8SFF Hardware Compatibility



Qualification date: June 2017



Component Description SKU
Chassis 1 RU server, 8 x 2.5″ SFF drives

Nodes per chassis: 1

Use cases:

  • Analytics and Big Data
  • Remote Office/Branch Office
  • End-User Computing / Virtual Desktop Infrastructure
755258-B21
Boot Drive and Accessory 1 x M.2 SSD with M.2 kit

120 GB HPE SATA RI M.2 KIT 788028-B21
150GB HPE SATA 6G RI M.2 Digitally Signed Firmware SSD 875317-B21  (EOS)
240 GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD 875488-B21  (EOS)
340 GB HPE SATA RI M.2 KIT 835563-B21  (EOS)
Power supply 2 x Hot-plug power supply
HPE 500W Flex Slot Platinum Hot-plug Power Supply Kit 720478-B21
HPE 800W Flex Slot Platinum Hot-plug Power Supply Kit 720479-B21
HPE 1400W Flex Slot Platinum Plus Hot-plug Power Supply Kit 720620-B21
HPE iLO License HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features 512485-B21



Table. storage
Component Description SKU
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
2 x 2.5″ SATA/SAS SSDs
480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
4 or 6 x 2.5″ HDDs
1TB HPE 2.5 inch 12Gbps SAS 7.2K RPM SFF SC HDD 832514-B21  (EOS)
1.8TB HPE SAS 12G Enterprise 10K SFF (2.5in) SC 512e Digitally Signed Firmware HDD 872481-B21
HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD 765466-B21
Storage: All-Flash Only SATA/SAS SSDs
4 or 8 x 2.5″ SATA/SAS SSDs
480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
Storage controller 1 x Storage Controller

HPE H240ar 12Gb 2-ports Int Smart HBA

726757-B21
HPE H240ar WIRE Smart HBA

749976-B21



Table. Broadwell: CPU and Memory
Component Description SKU
CPU 2 x Intel Xeon E5-2620v4, 8-core Broadwell @2.1GHz or higher CPUs

Various
Memory DDR4-2400, 1.2V, 16GB, RDIMM

  • 6 x 16 GB = 96 GB
  • 8 x 16 GB = 128 GB
  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
836220-B21
DDR4-2400, 1.2V, 32GB, RDIMM

  • 6 x 32 GB = 192 GB
  • 8 x 32 GB = 256 GB
  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
805351-B21
DDR4-2400, 1.2V, 64GB, LRDIMM

  • 6 x 64 GB = 384 GB
  • 8 x 64 GB = 512 GB
  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
805358-B21



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 or 2 x HPE Ethernet 10Gbps 2P 560FLR-SFP+ Adapter 665243-B21
PCIe Network Interface 1 or 2 x PCIe-slot Ethernet adapter
HPE Ethernet 10 Gbps 2-port 560SFP+ Adapter 665249-B21
HPE Ethernet 10Gb 2-port 561FLR-T Adapter 700699-B21

DL380 Gen9 8SFF Hardware Compatibility



Qualification date: June 2017



Component Description SKU
Chassis 2 RU server, 8 x 2.5″ SFF drives

Nodes per chassis: 1

Use cases:

  • Analytics and Big Data
  • Backup and Disaster Recovery
  • Files and Objects
  • Private Cloud
  • Test and Development
  • End-User Computing / Virtual Desktop Infrastructure
719064-B21
Boot Drive and Accessory 1 x M.2 SSD with M.2 kit

120 GB HPE SATA RI M.2 KIT 788028-B21
150GB HPE SATA 6G RI M.2 Digitally Signed Firmware SSD 875317-B21  (EOS)
240 GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD 875488-B21  (EOS)
340 GB HPE SATA RI M.2 KIT 835563-B21  (EOS)
Power supply 2 x Hot-plug power supplyHPE 1400W Flex Slot Platinum Plus Hot-plug Power Supply Kit 720620-B21
HPE iLO License HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features 512485-B21



Table. storage
Component Description SKU
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
2 x 2.5″ SATA/SAS SSDs
480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
4 or 6 x 2.5″ HDDs
1TB HPE 2.5 inch 12Gbps SAS 7.2K RPM SFF SC HDD 832514-B21  (EOS)
HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD 765466-B21
Storage: All-Flash Only SATA/SAS SSDs
4 or 8 x 2.5″ SATA/SAS SSDs
480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
Storage controller 1 x Storage Controller

HPE H240ar 12Gb 2-ports Int Smart HBA

726757-B21
HPE H240ar WIRE Smart HBA

749976-B21



Table. Broadwell: CPU and Memory
Component Description SKU
CPU 2 x Intel Xeon E5-2620v4, 8-core Broadwell @2.1GHz or higher CPUs

Various
Memory
DDR4-2400, 1.2V, 16GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
836220-B21
DDR4-2400, 1.2V, 32GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
805351-B21
DDR4-2400, 1.2V, 64GB, LRDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
805358-B21



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 or 2 x HPE Ethernet 10Gbps 2P 560FLR-SFP+ Adapter 665243-B21
PCIe Network Interface 1 or 2 x PCIe-slot Ethernet adapter
HPE Ethernet 10 Gbps 2-port 560SFP+ Adapter 665249-B21
HPE Ethernet 10Gb 2-port 561FLR-T Adapter 700699-B21



Table. But by the full GPU acceleration tech
Component Description SKU
HPE Computation and Graphics Accelerators 2 x HPE Computation and Graphics Accelerators

HPE NVIDIA Tesla M60 Reverse Air Flow Dual GPU PCIe Graphics Accelerator

M3X67A
NVIDIA Tesla M10 Quad GPU Module Q0J62A
Riser Kit GPU Ready Riser Kits
HPE DL380 Gen9 Secondary 3 Slot GPU Ready Riser Kit 719073-B21
HPE DL380 Gen9 Primary 2 Slot GPU Ready Riser Kit 719076-B21
Fan Kit HPE DL380 Gen9 High Performance Fan Kit 719079-B21
Enablement Kit HPE DL380 Gen9 Graphics Enablement Kit 719082-B21

DL380 Gen9 12LFF Hardware Compatibility



Qualification date: June 2017



Component Description SKU
Chassis 2 RU server, 12 x 3.5″ LFF drives

Nodes per chassis: 1

Use cases:

  • Analytics and Big Data
  • Backup and Disaster Recovery
  • Files and Objects
  • Private Cloud
  • Test and Development
  • End-User Computing / Virtual Desktop Infrastructure
719061-B21
Boot Drive and Accessory 1 x M.2 SSD with M.2 kit

120 GB HPE SATA RI M.2 KIT 788028-B21
150GB HPE SATA 6G RI M.2 Digitally Signed Firmware SSD 875317-B21  (EOS)
240 GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD 875488-B21  (EOS)
340 GB HPE SATA RI M.2 KIT 835563-B21  (EOS)
Power supply 2 x Hot-plug power supply
HPE 800W Flex Slot Platinum Hot-plug Power Supply Kit 720479-B21
HPE 1400W Flex Slot Platinum Plus Hot-plug Power Supply Kit 720620-B21
HPE iLO License HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features 512485-B21



Table. storage
Component Description SKU
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
2 or 4 x 3.5″ SATA/SAS SSDs
480GB HPE Hot-swappable (3.5in) SATA 6Gbps MU LFF SCC DS SSD 872346-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable (3.5in) SATA 6Gbps MU LFF SCC DS SSD 872350-B21  (EOS)
HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD P09718-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
4, 8, or 10 x 3.5″ HDDs

1TB HPE 3.5″ 12Gbps SAS 7.2K RPM LFF SC HDD 846524-B21  (EOS)
HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD 872485-B21
4TB HPE 3.5″ 12Gbps Midline SAS 7.2K RPM LFF SC DS HDD 872487-B21
6TB HPE 3.5″ 12Gbps Midline SAS 7.2K RPM LFF SC DS HDD 846514-B21  (EOS)
Storage: All-Flash Only SATA/SAS SSDs
8 or 12 x 3.5″ SATA/SAS SSDs
480GB HPE Hot-swappable (3.5in) SATA 6Gbps MU LFF SCC DS SSD 872346-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable (3.5in) SATA 6Gbps MU LFF SCC DS SSD 872350-B21  (EOS)
HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD P09718-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
Storage controller 1 x Storage Controller

HPE H240ar 12Gb 2-ports Int Smart HBA

726757-B21
HPE H240ar WIRE Smart HBA

749976-B21
storage expander card 1 x HPE 12GB DL380 GEN9 SAS Expander Card 727250-B21



Table. Broadwell: CPU and Memory
Component Description SKU
CPU 2 x Intel Xeon E5-2620v4, 8-core Broadwell @2.1GHz or higher CPUs

Various
Memory DDR4-2400, 1.2V, 16GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
836220-B21
DDR4-2400, 1.2V, 32GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
805351-B21
DDR4-2400, 1.2V, 64GB, LRDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
805358-B21



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 or 2 x HPE Ethernet 10Gbps 2P 560FLR-SFP+ Adapter 665243-B21
PCIe Network Interface 1 or 2 x PCIe-slot Ethernet adapter
HPE Ethernet 10 Gbps 2-port 560SFP+ Adapter 665249-B21
HPE Ethernet 10Gb 2-port 561FLR-T Adapter 700699-B21

DL380 Gen9 24SFF Hardware Compatibility



Qualification date: June 2017



Component Description SKU
Chassis 2 RU server, 24 x 2.5″ SFF drives

Nodes per chassis: 1

Use cases:

  • Analytics and Big Data
  • Database and Business Critical Apps
  • Private Cloud
  • Test and Development
  • End-User Computing / Virtual Desktop Infrastructure
767032-B21
Boot Drive and Accessory 1 x M.2 SSD with M.2 kit

120 GB HPE SATA RI M.2 KIT 788028-B21
150GB HPE SATA 6G RI M.2 Digitally Signed Firmware SSD 875317-B21  (EOS)
240 GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD 875488-B21  (EOS)
340 GB HPE SATA RI M.2 KIT 835563-B21  (EOS)
Power supply 2 x Hot-plug power supply
HPE 800W Flex Slot Platinum Hot-plug Power Supply Kit 720479-B21
HPE 1400W Flex Slot Platinum Plus Hot-plug Power Supply Kit 720620-B21
HPE iLO License HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features 512485-B21



Table. storage
Component Description SKU
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
4 or 8 x 2.5″ SATA/SAS SSDs
480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
8, 16, or 20 x 2.5″ HDDs

1TB HPE 2.5 inch 12Gbps SAS 7.2K RPM SFF SC HDD 832514-B21  (EOS)
1.8TB HPE SAS 12G Enterprise 10K SFF (2.5in) SC 512e Digitally Signed Firmware HDD 872481-B21
HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD 765466-B21
Storage: All-Flash Only SATA/SAS SSDs
8, 16, or 24 x 2.5″ SATA/SAS SSDs
480GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872344-B21  (EOS)
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09090-B21
960GB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872348-B21  (EOS)
1.92TB HPE Hot-swappable 2.5″ SATA 6Gbps MU SFF SC DS SSD 872352-B21  (EOS)
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD P09722-B21
3.84TB HPE Hot-swappable 2.5″ SAS 12Gbps Read Intensive SFF SC DS SSD 872394-B21  (EOS)
Storage controller 1 x Storage Controller

HPE H240ar 12Gb 2-ports Int Smart HBA

726757-B21
HPE H240ar WIRE Smart HBA

749976-B21
storage expander card 1 x HPE 12GB DL380 GEN9 SAS Expander Card 727250-B21



Table. Broadwell: CPU and Memory
Component Description SKU
CPU 2 x Intel Xeon E5-2620v4, 8-core Broadwell @2.1GHz or higher CPUs

Various
Memory DDR4-2400, 1.2V, 16GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
836220-B21
DDR4-2400, 1.2V, 32GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
805351-B21
DDR4-2400, 1.2V, 64GB, LRDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
805358-B21



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 or 2 x HPE Ethernet 10Gbps 2P 560FLR-SFP+ Adapter 665243-B21
PCIe Network Interface 1 or 2 x PCIe-slot Ethernet adapter
HPE Ethernet 10 Gbps 2-port 560SFP+ Adapter 665249-B21
HPE Ethernet 10Gb 2-port 561FLR-T Adapter 700699-B21

Some segments we help



Third-party maintenance for Nutanix End-of-Life (EOL) and Nutanix End-of-Service-Life (EOSL)



A DC Parts made an analysis on more than 250 customer contracts that use storage, servers, networks and tapes and showed us that 40-60% of the equipment of these customers operate beyond the end dates of support.

There are simple options for you to reduce your expenses and feel more confident about your IT infrastructure. When you choose a custom solution to extend the life of your IT equipment, you can make big savings.



How can we help:



We offer our customers a unique assessment to help analyze their OEM support contracts and understand exactly which devices can be supported in the most affordable way, without compromising their performance.



Nutanix hardware support



Support services DC Parts provide support for Nutanix hardware. We work to match the right approach with the right equipment to meet your Nutanix hardware support needs.

With a highly trained team of certified engineers ready to troubleshoot any Nutanix hardware issues, DC Parts is uniquely qualified to serve you. If you would like to speak with a representative about purchasing support on Nutanix hardware, contact us.

A DC Parts helps companies of all sizes better manage their IT data centers by providing third-party support services to leading equipment manufacturers, including: Dell, IBMHPEnetapp, Oracle SunCisco and more.

With support DC Parts, we manage all your hardware, between the manufacturers through a link. Support from DC Parts offers flexible service level agreements, certified engineering support teams and dedicated customer service representatives.

Extend the life and value of your IT assets. Contact DC Parts Support immediately.

Contact DC Parts and we will help you better optimize your IT investment



Contact DcParts



About DC Parts





Questions?

Call our product team at 011 3022-4694 or send an email to: contato@dcparts.com.br

Warranty:

All the hardware in the DC Parts is fully tested, guaranteed and comes with a 90-day warranty. Above all, we will support you before, during and after the sale.



Product Experience:

In other words, we know how important it is that you get the product you need to meet your needs. In addition, we have a sales team and agile logistics to make the shortest possible delivery times possible.

Sending proposals within 2 business days, experimenting with data centers and integrators and we always try to get the best price.

Do not hesitate to contact us with any questions about compatibility, condition or the best product available for your need.

Our website represents only a fraction of the pieces we work with. But you can contact your complete requirements or equipment lists.

Translate »
Select currency
error: Content is protected !!
Open chat
Need help?
