Hardware support and maintenance Nutanix Dell PowerEdge
The Nutanix hardware you have in your IT infrastructure can still provide the functionality, flexibility and practicality for the vast majority of organizations today. The ability to add additional memory (if not already specified at time of purchase) and CPU provides customers with a variety of options to upgrade their host servers (virtualized environments) to continue to deliver the required performance beyond the manufacturers' end-of-life dates. These potential upgrade options mean that customers do not have to constantly look for new server solutions at the end of a 3 or 5 year internal lifecycle program because the servers are no longer fit for purpose.
Nutanix hardware from partners
Outsourcing Nutanix Hardware Maintenance
A DC Parts provides organizations with a viable and sustainable alternative option to extend the life of their Nutanix hardware after 'end of life' or 'end of support life' announcements, being able to provide recommended hardware upgrade options which include and incorporates complete installation and configuration work performed by experienced technical field engineers. Our ability to continue to provide an alternative server maintenance support service for Nutanix hardware further assists organizations by providing a cost-effective solution for mission-critical Nutanix hardware. This solution significantly lowers your total cost of ownership and also generates a greater return on your initial capital expenditures for IT server hardware.
A DC Parts offers a flexible approach for organizations looking to integrate partially or fully into their organization's maintenance and support services for current or historic server systems. These service levels range from NBD (Next Business Day) to a 24/7 response. Our maintenance and support services range from parts only to telephone and remote support. Our service level pages describe these and other services in detail.
Get in touch with us to see if we can provide the guarantees you need, especially to explore an alternative maintenance support service.
Asset Residual Value for Your Nutanix Hardware
Our exclusive maintenance and support service for Nutanix hardware can provide you with the potential to customize a cost-neutral maintenance contract for Nutanix hardware that is now post-warranty, end of life or end of life (EOL / EOSL). Our service allows customers with Nutanix hardware to have multiple stages in a lifecycle program, while providing extended maintenance support regardless of the need for 3,6,9 or even 12 months of support, thus effectively creating a solution neutral in terms of cost.
Cost reduction in your contract
We allow a cost neutral maintenance solution to be provided through the residual value on your Nutanix hardware that we would remove at the end of the agreed maintenance support term. As well as services for secure deactivation and elimination of data according to internal compliance requirements will also be part of the discussion of the hardware lifecycle services program.
If you don't need a support service, our maintenance service can still benefit you. As such, we can provide a residual value quote for your IT server and storage hardware and discuss the decommissioning and data erasure process, allowing you to achieve a much greater return on your initial capital investment. There is no obligation to obtain a quote from DC Parts, but lets you explore whether this service might be viable and beneficial for you.
Nutanix Hardware with Dell PowerEdge
Nutanix Dell PowerEdge R440 8SFF
Nutanix Dell PowerEdge R640 10 SFF
Nutanix Dell PowerEdge R640 4 LFF
Nutanix Dell PowerEdge R740xd 12 LFF
Nutanix Dell PowerEdge R740xd 24 SFF
Nutanix Dell PowerEdge R630 10 SFF
Nutanix Dell PowerEdge R730xd 12 LFF
Nutanix Dell PowerEdge R730xd 24 SFF
Nutanix Dell PowerEdge R730 16 SFF
Nutanix Hardware with Dell PowerEdge
Hyper-converged infrastructure (HCI) is becoming a significant service platform in the datacenter, and with good reason. Processing abstraction, storage and network resources to create a fully software-defined network datacenter is the logical progression of the decade of virtualization trend. Companies like Nutanix are leading the way, enabling IT departments to create and expand application environments by simply adding common off-the-shelf servers. Eliminating the expense and complexity of deploying and managing a datacenter full of disparate devices with a mix of management interfaces plus multiple networking and storage protocols make it easier to deploy and support an on-premises cloud.
As a leading provider of enterprise servers, the Dell EMC product line is a recognized standard when it comes to data center deployments. The PowerEdge platform is an ideal building block for a Nutanix private cloud. Dell EMC's partnership with Nutanix extends to XC series appliances – one and two rack unit PowerEdge servers specifically certified to support the Nutanix HCI solution.
A DC Parts has a deep understanding of Dell PowerEdge hardware and our team has years of experience with PowerEdge systems. THE DC Parts You can customize a support package to meet your organization's immediate or long-term needs, from short-term 9-5 contracts to 24/7 annual maintenance packages. The consultants of DC Parts work with clients to ensure they get the guarantees they need at a cost that fits their budget. Our flexibility, along with our comprehensive understanding of the PowerEdge range, allows DC Parts help organizations maximize investment in their IT infrastructure.
Benefits of maintenance support DC Parts in hardware Nutanix com Dell PowerEdge
- Technical diagnostics and repair of Dell PowerEdge servers
- Level 3 engineer assigned to an account
- Global service availability
- Maintenance support for current and end-of-life Dell equipment
- Pro-rata support and co-termination dates
- Site audits / surveys
- Data / platform migration
- IT decommissioning
- Data erasure
- Highly experienced and specially trained technical field engineers
- On-site spare parts cache
- Various methods for generating a fault ticket ticket
- Helpdesk assistance
- Operating system and firmware recommendations
- Professional services
- Consulting
- VMware
- Hardware upgrades
- Flexible short and long-term maintenance support contracts
- Hardware rental
- DMR (digital media retention)
- Operational savings
End of support Nutanix with hardware Dell PowerEdge, but not DC Parts
Supported Models
- Dell™ 14th Generation PowerEdge™ Servers
- Dell™ 13th Generation PowerEdge™ Servers
Nutanix Dell PowerEdge R440 8SFF
R440 8SFF Hardware Compatibility
| Component | Description | SKU |
|---|---|---|
| Chassis | 2.5″ Chassis with up to 8 Hot Plug Hard Drives Nodes per chassis: 1 Use cases: Analytics and Big Data Remote Office/Branch Office End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported. | 321-BCUV |
| boot drive | 1 x BOSS controller card + with 2 M.2 Sticks 240G (RAID 1), LP | 403-BBPZ |
| Power Supply | 1 x Dual, Hot Plug, Redundant Power Supply (1 + 1), 550W | 450-AGOY |
| Embedded Systems Management | iDRAC9 Basic | 385-BBLD |
| iDRAC Password | iDRAC, Factory Generated Password | 379-BCSF |
| Component | Description | SKU |
| Storage: All-Flash | Only SAS SSDs | |
| 2, 4, 6, or 8 x 2.5″ SAS SSDs | ||
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASFI | |
| 960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW | 400-BDSI | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW | 400-BEPD | |
| 1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, | 400-BDSU | |
| Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 | 400-BCVC | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCOM | |
| 1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW | 400-BEQI | |
| 1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 | 400-BCMJ | |
| 1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5 ″, ISE, Samsung, PM883a, PE / PV | 345-BBHN | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW | 400-BDNK | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW | 400-AYZI | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW | 400-BBQX | |
| 7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW | 345-BBBP | |
| Storage Controller | 1 x Storage Controller | |
| HBA330 Controller Adapter, Low Profile | 405-AANK | |
| HBA330 12Gbps SAS HBA Controller (NON-RAID), MiniCard | 405-AAJW | |
| RAID Option | In RAID | 780-BCDI |
| Component | Description | SKU |
| CPU | 2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU). | Various |
| Memory | Note: Order the memory configuration SKU 370-AAIP (Performance Optimized) along with the memory DIMMs. | |
| DDR4-2666, 1.2V, 16GB, RDIMM 16x16GB = 256GB | 370-ADND | |
| DDR4-2666, 1.2V, 32GB, RDIMM 16x32GB = 512GB | 370-DNF | |
| Component | Description | SKU |
| PCIe Network Interface | 1 x Intel X710 Dual Port 10GbE SFP + Adapter, PCIe Low Profile | 555-BACKN |
Nutanix Dell PowerEdge R640 10 SFF
R640 10 SFF Hardware Compatibility
| Component | Description | SKU |
|---|---|---|
| Chassis | Use cases:Analytics and Big Data Remote Office/Branch Office End-User Computing/Virtual Desktop Infrastructure Note:Only Legacy BIOS is supported. For chassis with NVMe support, order the chassis SKU 321-BCQQ. | |
| PowerEdge R640 ServerNodes per chassis: 1 | 210-AKWU | |
| 2.5 Chassis with up to 10 Hard Drives and 3PCIe slotsNodes per chassis: 1 | 321-BCQL | |
| 2.5″ Chassis with up to 10 Hard Drives, 8 NVMe Drives and 3PCIe Slots, 2CPU onlyNodes per chassis: 1 | 321-BCQQ | |
| boot drive | 1 x M.2 SSD | |
| BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),LP | 403-BBPM | |
| BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),LP | 403-BBPZ | |
| BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),LP | 403-BCHI | |
| BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP | 403-BBUU | |
| BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP | 403-BCHH | |
| Power Supply | 1 x Dual, Hot-plug power supply | |
| 750W Dual, Hot-plug, Redundant Power Supply (1+1) | 450-ADWS | |
| Dual, Hot plug, Redundant Power Supply (1+1), 1100W | 450-ADWM | |
| Embedded Systems Management | iDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise | 385-BBKT |
| iDRAC Password | iDRAC, Legacy Password | 379-BCSG |
| Component | Description | SKU |
| Storage: All-Flash | Only SATA/SAS SSDs | |
| 2, 4, 6, 8, or 10 x 2.5″ SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions. | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ARXG (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASEO (EOS) | |
| 480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive | 400-BDSD (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQG (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW | 400-AZHC (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW | 400-AZII (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASFO (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASFI | |
| 960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, S4600, 3 DWPD, 5256 TBW | 400-ASYL (EOS) | |
| 960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW | 400-BDSI | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW | 400-BEPD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASGE (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW | 400-ASFZ | |
| 1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, | 400-BDSU | |
| Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 | 400-BCVC | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCOM | |
| 1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW | 400-BEQI | |
| 1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 | 400-BCMJ | |
| 1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5 ″, ISE, Samsung, PM883a, PE / PV | 345-BBHN | |
| 3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW | 400-ASGI | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW | 400-AYZI | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW | 400-BDNK | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW | 400-BBQX | |
| 7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW | 345-BBBP | |
| Storage: All-Flash | Only SATA/SAS and NVMe SSDs | |
| 6 or 8 x 2.5″ SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions. | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ARXG (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASEO (EOS) | |
| 480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive | 400-BDSD (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW | 400-AZHC (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW | 400-AZII (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASFO (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASFI | |
| 960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW | 400-BDSI | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW | 400-BEPD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASGE (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW | 400-ASFZ | |
| 1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, | 400-BDSU | |
| 1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW | 400-BEQI | |
| 1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5 ″, ISE, Samsung, PM883a, PE / PV | 345-BBHN | |
| 3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW | 400-ASGI | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW | 400-AYZI | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW | 400-BDNK | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW | 400-BBQX | |
| 7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW | 345-BBBP | |
| 2 or 4 x 2.5 ″ NVMe SSDs | ||
| Dell 800GB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier | 400-AUMO (EOS) | |
| Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier | 400-AUMP (EOS) | |
| Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier | 400-BELT | |
| Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725b with Carrier | 400-BEFC | |
| Dell 3.2TB NVMe Mix Use Express Flash 2.5in SFF Drive U.2 P4610 | 400-BEDQ | |
| Dell 6.4TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier | 400-BELR | |
| Storage: Hybrid | Mix of SATA/SAS SSDs and HDDs | |
| 2 x 2.5″ SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions. | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ARXG (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASEO (EOS) | |
| 480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive | 400-BDSD (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQG (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW | 400-AZHC (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW | 400-AZII (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASFO (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASFI | |
| 960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW | 400-BDSI | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW | 400-BEPD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASGE (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW | 400-ASFZ | |
| 1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, | 400-BDSU | |
| Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 | 400-BCVC | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCOM | |
| 1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW | 400-BEQI | |
| 1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 | 400-BCMJ | |
| 1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5 ″, ISE, Samsung, PM883a, PE / PV | 345-BBHN | |
| 3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW | 400-ASGI | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW | 400-AYZI | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW | 400-BDNK | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW | 400-BBQX | |
| 7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW | 345-BBBP | |
| 4, 6, or 8 x 2.5″ HDDs | ||
| 1TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive | 400-ASH | |
| 1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive | 400-ASHI | |
| 1.2TB 10K RPM Self-Encrypting SAS 12Gbps 512n 2.5in Hot-plug Hard Drive, FIPS140 | 400-ASHK | |
| 1.8TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive | 400-ARXC | |
| 2TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive | 400-ASHP | |
| 2.4TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive | 400-AVEZ | |
| 2.4TB 10K RPM Self-Encrypting SAS 12Gbps 512e 2.5in Hot-plug Hard Drive, FIPS140 | 400-AVHH | |
| Storage Controller | 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard | 405-YYYY |
| RAID Option | In RAID | 780-BCDI |
| Component | Description | SKU |
| CPU | 2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU). | Various |
| Memory | Note: Order the memory configuration SKU 370-AAIP (Performance Optimized) along with the memory DIMMs. | |
| DDR4-2666, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB | 370-ADND | |
| DDR4-2666, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-DNF | |
| DDR4-2666, 1.2V, 64GB, LRDIMM12 x 64GB = 768GB 16 x 64GB = 1TB 24 x 64GB = 1.5TB Note: Select 2666MT/s LRDIMMs (SKU 370-ADNT) for memory DIMM type and speed option. | 370-DNA | |
| DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB Note:Select 2666MT/s LRDIMMs (SKU 370-ADNT) for Memory DIMM Type and Speed option. For memory capacity higher than 768 GB and up to 1.5 TB per socket, order the Intel Skylake Xeon CPUs with suffix M. | 370-ADMX | |
| Component | Description | SKU |
| CPU | 2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU). | Various |
| Memory | Note: Order the memory configuration SKU 370-AAIP (Performance Optimized) along with the memory DIMMs. | |
| DDR4-3200, 1.2V, 8 GB, RDIMM12 x 8 GB = 96 GB 16 x 8 GB = 128 GB 24 x 8 GB = 192 GB | 370-AEVO | |
| DDR4-2933, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB | 370-AQF | |
| DDR4-3200, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB | 370-AEVQ | |
| DDR4-2933, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-AEQH | |
| DDR4-3200, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-EVN | |
| DDR4-2933, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB | 370-AQD | |
| DDR4-3200, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB | 370-EVP | |
| DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB | 370-ADMX | |
| Component | Description | SKU |
| FlexibleLOM Adapter | 1 x Flexible LAN on Motherboard (FLOM) adapter | |
| Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28, rNDC | 406-BBLG | |
| Intel X550 Quad Port 10GbE BASE-T, rNDC | 540-BBUY | |
| Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBUZ | |
| Intel Ethernet I350 QP 1Gb Network Daughter Card | 540-BBB | |
| Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC | 540-BBUK | |
| Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC | 540-BOOM | |
| Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC | 555-BCKO | |
| PCIe Network Interface | 1x PCIe Network Interface | |
| Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile | 406-BBLD | |
| Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile | 540-BBRL | |
| Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Low Profile, Customer Install | 540-BCCN | |
| Intel Ethernet i350 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile | 540-BBCZ | |
| Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile | 540-BBVK | |
| Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Low Profile | 540-BBDB | |
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile | 540-BBVJ | |
| Intel XXV710 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile | 540-BCCM | |
| Broadcom 57412 Dual Port 10GbE SFP + Adapter, PCIe Low Profile | 540-BBVI | |
| Mellanox ConnectX-5 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile | 540-BCMQ | |
| Broadcom 57412 Dual Port 10GbE SFP+ & 5720 Dual Port 1GbE BASE-T rNDC | 540-BUL | |
| Intel X710 Dual Port 10GbE SFP+ Adapter, PCIe Low Profile | 555-BACKN | |
| Dual NIC Configuration | Note: Dual 10G Base-T NICs, 1 x 540-BBUY + 1 x 540-BBRL Dual 10G SFP+ NICs, 1 x 555-BCKO + 1 x 555-BCKN Dual 25G NICs, 1 x 406-BBLG + 1 x 406- BBLD |
Nutanix Dell PowerEdge R640 4 LFF
R640 4 LFF Hardware Compatibility
Qualification date: March 2018
| Component | Description | SKU |
|---|---|---|
| Chassis | Use cases: Remote Office/Branch Office | |
| PowerEdge R640 Server Nodes per chassis: 1 | 210-AKWU | |
| 3.5 Chassis with up to 4 Hard Drives and 3PCIe slots Nodes per chassis: 1 | 321-BCQF | |
| boot drive | 1 x M.2 SSD | |
| BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),LP | 403-BBPM | |
| BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),LP | 403-BBPZ | |
| BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),LP | 403-BCHI | |
| BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP | 403-BBUU | |
| BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP | 403-BCHH | |
| Power Supply | 2x Hot plug power supply | |
| 750W Dual, Hot-plug, Redundant Power Supply (1+1) | 450-ADWS | |
| Dual, Hot plug, Redundant Power Supply (1+1), 1100W | 450-ADWM | |
| Embedded Systems Management | iDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise | 385-BBKT |
| iDRAC Password | iDRAC, Legacy Password | 379-BCSG |
| Component | Description | SKU |
|---|---|---|
| Storage: All-Flash | Only SATA/SAS SSDs | |
| 2 or 4 x 3.5″ SATA/SAS SSDs | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a | 400-ACES (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASEP (EOS) | |
| 480GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSV (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQG (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQD (EOS) | |
| 800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW | 400-AZFZ (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a | 400-ASFP (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASFJ (EOS) | |
| 960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, S4600, 3DWPD, 5256TBW | 400-ASYM (EOS) | |
| 960GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSW | |
| 960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW | 400-BCQF | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V, 3 DWPD, 5256 TBW | 400-BEQD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a | 400-ASGF (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASGB (EOS) | |
| 1.92TB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSY | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCOM | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCPF | |
| 1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW | 400-BEPQ | |
| 1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW | 400-BEQT | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW | 400-AYYB | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008TBW | 400-BDMN | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW | 400-BBQ | |
| 7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW | 345-BBCH | |
| Storage: Hybrid | Mix of SATA/SAS SSDs and HDDs | |
| 2 x 3.5″ SATA/SAS SSDs | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a | 400-ACES (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASEP (EOS) | |
| 480GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSV (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQG (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQD (EOS) | |
| 800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW | 400-AZFZ (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a | 400-ASFP (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASFJ (EOS) | |
| 960GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSW | |
| 960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW | 400-BCQF | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V, 3 DWPD, 5256 TBW | 400-BEQD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a | 400-ASGF (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASGB (EOS) | |
| 1.92TB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSY | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCOM | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCPF | |
| 1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW | 400-BEPQ | |
| 1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW | 400-BEQT | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW | 400-AYYB | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008TBW | 400-BDMN | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW | 400-BBQ | |
| 7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW | 345-BBCH | |
| 2 x 3.5 ″ HDDs | ||
| 1TB 7.2K RPM NLSAS 12Gbps 512n 2.5in Hot-plug Hard Drive, 3.5in HYB CARR | 400-ASKF | |
| 2TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-Plug Hard Drive | 400-ASH | |
| 4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive | 400-ASHY | |
| 8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive | 400-ASIB | |
| 8TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 | 400-ASID | |
| 8 TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive | 400-ASUG | |
| 12TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive | 400-AWIP | |
| 12TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 | 400-AXN | |
| 12TB 7.2K SAS 12Gbps 512e 3.5in Hot-Plug Hard Drive | 400-BEJR | |
| Storage Controller | 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard | 405-YYYY |
| RAID Option | In RAID | 780-BCDI |
| Component | Description | SKU |
|---|---|---|
| CPU | 1 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU). | Various |
| Memory | DDR4-2666, 1.2V, 16GB, RDIMM
| 370-ADND |
DDR4-2666, 1.2V, 32GB, RDIMM
| 370-DNF | |
DDR4-2666, 1.2V, 64GB, LRDIMM
| 370-DNA | |
DDR4-2667, 1.2V, 128GB, LRDIMM
| 370-ADMX |
| Component | Description | SKU |
|---|---|---|
| CPU | 1 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU). | Various |
| Memory | DDR4-3200, 1.2V, 8GB, RDIMM
| 370-AEVO |
DDR4-2933, 1.2V, 16GB, RDIMM
| 370-AQF | |
DDR4-3200, 1.2V, 16GB, RDIMM
| 370-AEVQ | |
DDR4-2933, 1.2V, 32GB, RDIMM
| 370-AEQH | |
DDR4-3200, 1.2V, 32GB, RDIMM
| 370-EVN | |
DDR4-2933, 1.2V, 64GB, RDIMM
| 370-AQD | |
DDR4-3200, 1.2V, 64GB, RDIMM
| 370-EVP | |
DDR4-2667, 1.2V, 128GB, LRDIMM
| 370-ADMX |
| Component | Description | SKU |
|---|---|---|
| FlexibleLOM Adapter | 1 x Flexible LAN on Motherboard (FLOM) adapter | |
| Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28, rNDC | 406-BBLG | |
| Intel X550 Quad Port 10GbE BASE-T, rNDC | 540-BBUY | |
| Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBUZ | |
| Intel Ethernet I350 QP 1Gb Network Daughter Card | 540-BBB | |
| Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC | 540-BBUK | |
| Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC | 540-BOOM | |
| Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC | 555-BCKO | |
| PCIe Network Interface | 1x PCIe Network Interface | |
| Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile | 406-BBLD | |
| Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile | 540-BBRL | |
| Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Full Height, Customer Install | 540-BCDG | |
| Intel Ethernet i350 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile | 540-BBCZ | |
| Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile | 540-BBVK | |
| Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Low Profile | 540-BBDB | |
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile | 540-BBVJ | |
| Intel XXV710 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile | 540-BCCM | |
| Broadcom 57412 Dual Port 10GbE SFP + Adapter, PCIe Low Profile | 540-BBVI | |
| Mellanox ConnectX-5 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile | 540-BCMQ | |
| Broadcom 57412 Dual Port 10GbE SFP+ & 5720 Dual Port 1GbE BASE-T rNDC | 540-BUL | |
| Intel X710 Dual Port 10GbE SFP+ Adapter, PCIe Low Profile | 555-BACKN | |
| Dual NIC Configuration | ||
Nutanix Dell PowerEdge R740xd 12 LFF
R740xd 12 LFF Hardware Compatibility
| Component | Description | SKU |
|---|---|---|
| Chassis | Use cases:Analytics and Big Data Backup and Disaster Recovery Files and Objects Private Cloud Test and Development End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported. | |
| PowerEdge R740xd ServerNodes per chassis: 1 | 210-AKZR | |
| Chassis with Up to 12 x 3.5 Hard Drives for 2CPU ConfigurationNodes per chassis: 1 | 321-BCPU | |
| boot drive | 1 x M.2 SSD | |
| BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),FH | 403-BBPJ | |
| BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),FH | 403-BBPT | |
| BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),FH | 403-BCHP | |
| BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH | 403-BBSV | |
| BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH | 403-BCHJ | |
| Power Supply | 2x Hot plug power supply | |
| 750W Dual, Hot-plug, Redundant Power Supply (1+1) | 450-ADWS | |
| Dual, Hot plug, Redundant Power Supply (1+1), 1100W | 450-ADWM | |
| Dual, Hot-plug, Redundant Power Supply (1 + 1), 1600W, 250 Volt Power Cord Required for Use | 450-AFMQ | |
| Embedded Systems Management | iDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise | 385-BBKT |
| iDRAC Password | iDRAC, Legacy Password | 379-BCSG |
| Component | Description | SKU |
| Storage: All-Flash | Only SATA/SAS SSDs | |
| 4, 6, 8, 10, or 12 x 3.5″ SATA/SAS SSDsNote: The SSD SKUs 400-AYYB, 400-BDMN, 400-BDSW, 400-BDSY, and 400-BDSV are supported with Foundation 4.3.4 and higher versions. | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a | 400-ACES (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASEP (EOS) | |
| 480GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSV (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQG (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQD (EOS) | |
| 800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW | 400-AZFZ (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a | 400-ASFP (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASFJ (EOS) | |
| 960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, S4600, 3DWPD, 5256TBW | 400-ASYM (EOS) | |
| 960GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSW | |
| 960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW | 400-BCQF | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V, 3 DWPD, 5256 TBW | 400-BEQD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a | 400-ASGF (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASGB (EOS) | |
| 1.92TB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSY | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCOM | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCPF | |
| 1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW | 400-BEPQ | |
| 1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW | 400-BEQT | |
| 3.84TB SSD SAS RI 12Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, PM1633a | 400-ASGK (EOS) | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW | 400-AYYB | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008TBW | 400-BDMN | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW | 400-BBQ | |
| 7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW | 345-BBCH | |
| Storage: Hybrid | Mix of SATA/SAS SSDs and HDDs | |
| 2 or 4 x 3.5″ SATA/SAS SSDsNote: The SSD SKUs 400-AYYB, 400-BDMN, 400-BDSW, 400-BDSY, and 400-BDSV are supported with Foundation 4.3.4 and higher versions. | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a | 400-ACES (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASEP (EOS) | |
| 480GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSV (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQG (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQD (EOS) | |
| 800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW | 400-AZFZ (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a | 400-ASFP (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASFJ (EOS) | |
| 960GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSW | |
| 960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW | 400-BCQF | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V, 3 DWPD, 5256 TBW | 400-BEQD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a | 400-ASGF (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV | 400-ASGB (EOS) | |
| 1.92TB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive | 400-BDSY | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCOM | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCPF | |
| 1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW | 400-BEPQ | |
| 1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW | 400-BEQT | |
| 3.84TB SSD SAS RI 12Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, PM1633a | 400-ASGK (EOS) | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW | 400-AYYB | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008TBW | 400-BDMN | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW | 400-BBQ | |
| 7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW | 345-BBCH | |
| 4, 6, 8, or 10 x 3.5″ HDDsNote: The HDDs need to be twice or more the number of SSDs. | ||
| 1TB 7.2K RPM NLSAS 12Gbps 512n 2.5in Hot-plug Hard Drive, 3.5in HYB CARR | 400-ASKF | |
| 2TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-Plug Hard Drive | 400-ASH | |
| 2.4TB 10000rpm Sas-12gbps 512e 256mb Buffer 2.5inch (in 3.5inch Hybrid Carrier) | 400-ANTE | |
| 4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive | 400-ASHY | |
| 4TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive, FIPS140 | 400-ASHZ | |
| 8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive | 400-ASIB | |
| 8TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 | 400-ASID | |
| 8 TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive | 400-ASUG | |
| 12TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 | 400-AXN | |
| 12TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive | 400-AWIP | |
| 12TB 7.2K SAS 12Gbps 512e 3.5in Hot-Plug Hard Drive | 400-BEJR | |
| Storage Controller | 1 x Storage Controller | |
| HBA330 Controller Adapter, Low Profile | 405-AANK | |
| HBA330 12Gbps SAS HBA Controller (NON-RAID), MiniCard | 405-AAJW | |
| RAID Option | In RAID | 780-BCDI |
| Component | Description | SKU |
| CPU | 2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU). | Various |
| Memory | DDR4-2666, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB | 370-ADND |
| DDR4-2666, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-DNF | |
| DDR4-2666, 1.2V, 64 GB, LRDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Select 2666MT/s LRDIMMs (SKU 370-ADNT) for Memory DIMM Type and Speed option. | 370-DNA | |
| DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB Note:Select 2666MT/s LRDIMMs (SKU 370-ADNT) for Memory DIMM Type and Speed option. For memory capacity higher than 768 GB and up to 1.5 TB per socket, order the Intel Skylake Xeon CPUs with suffix M. | 370-ADMX | |
| Component | Description | SKU |
| CPU | 2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU). | Various |
| Memory | DDR4-3200, 1.2V, 8 GB, RDIMM12 x 8 GB = 96 GB 16 x 8 GB = 128 GB 24 x 8 GB = 192 GB | 370-AEVO |
| DDR4-2933, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB | 370-AQF | |
| DDR4-3200, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB | 370-AEVQ | |
| DDR4-2933, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-AEQH | |
| DDR4-3200, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-EVN | |
| DDR4-2933, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB | 370-AQD | |
| DDR4-3200, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB | 370-EVP | |
| DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB | 370-ADMX | |
| Component | Description | SKU |
| FlexibleLOM Adapter | 1 x Flexible LAN on Motherboard (FLOM) adapter | |
| Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28, rNDC | 406-BBLG | |
| Intel X550 Quad Port 10GbE BASE-T, rNDC | 540-BBUY | |
| Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBUZ | |
| Intel Ethernet I350 QP 1Gb Network Daughter Card | 540-BBDD | |
| Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBBB | |
| Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC | 540-BBUK | |
| Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC | 540-BOOM | |
| Intel Ethernet I350 QP 1Gb Network Daughter Card | 540-BBB | |
| Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC | 555-BCKO | |
| PCIe Network Interface | 1x PCIe Network Interface | |
| Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28 Adapter, PCIe Full Height | 406-BBLE | |
| Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Full Height | 540-BBRO | |
| Intel X710 Dual Port 10GbE Direct Attach SFP+ Adapter, PCIe Full Height | 540-BBHP | |
| Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Full Height, Customer Install | 540-BCDG | |
| Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Full Height | 540-BBDH | |
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Full Height | 540-BBUI | |
| Broadcom 57412 Dual Port 10GbE SFP+ Adapter, PCIe Full Height | 540-BBUH | |
| Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height | 540-BBCT | |
| Intel XXV710 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height | 540-BCDH | |
| Mellanox ConnectX-5 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Full Height | 540-BCNM | |
| Mellanox ConnectX-5 EX Dual Port 40 / 100GbE QSFP28 Adapter, PCIe Full Height | 540-BCIU | |
| Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height | 540-BBUJ | |
| Dual NIC Configuration | Note: Dual 10G Base-T NICs, 1 x 540-BBUY + 1 x 540-BBRO Dual 10G SFP+ NICs, 1 x 555-BCKO + 1 x 540-BBHP Dual 25G NICs, 1 x 406-BBLG + 1 x 406- BBLE |
Nutanix Dell PowerEdge R740xd 24 SFF
R740xd 24 SFF Hardware Compatibility
| Component | Description | SKU |
|---|---|---|
| Chassis | Use cases:Analytics and Big Data Database and Business Critical Apps Private Cloud Test and Development End-User Computing/Virtual Desktop Infrastructure Note:Only Legacy BIOS is supported. For chassis with GPU support, order the chassis SKU 321-BDHZ. For GPU support, order the power supply SKU 450-AGFO. For chassis with NVMe support, order the chassis SKU 321-BCRC. | |
| PowerEdge R740xd ServerNodes per chassis: 1 | 210-AKZR | |
| Chassis with Up to 24 x 2.5″ Hard Drives for 2CPUNodes per chassis: 1 | 321-BCPY | |
| Chassis with Up to 24 x 2.5 Hard Drives for 2CPU, GPU Capable ConfigurationNodes per chassis: 1 | 321-BDHZ | |
| Chassis up to 24 x 2.5 Hard Drives including 12 NVME Drives, 2CPU ConfigurationNodes per chassis: 1 | 321-BCRC | |
| boot drive | 1 x M.2 SSD | |
| BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),FH | 403-BBPJ | |
| BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),FH | 403-BBPT | |
| BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),FH | 403-BCHP | |
| BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH | 403-BBSV | |
| BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH | 403-BCHJ | |
| Power Supply | 2x Hot plug power supply | |
| 750W Dual, Hot-plug, Redundant Power Supply (1+1) | 450-ADWS | |
| Dual, Hot plug, Redundant Power Supply (1+1), 1100W | 450-ADWM | |
| Dual, Hot-plug Power Supply, 2400W, 250 Volt Power Cord Required for Use | 450-AGFO | |
| Dual, Hot-plug, Redundant Power Supply (1 + 1), 1600W, 250 Volt Power Cord Required for Use | 450-AFMQ | |
| Embedded Systems Management | iDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise | 385-BBKT |
| iDRAC Password | iDRAC, Legacy Password | 379-BCSG |
| Component | Description | SKU |
| Storage: All-Flash | Only SATA/SAS SSDs | |
| 8, 10, 12, 14, 16, 18, 20, 22, or 24 x 2.5″ SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions. | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ARXG (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASEO (EOS) | |
| 480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive | 400-BDSD (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQG (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW | 400-AZHC (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW | 400-AZII (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASFO (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASFI | |
| 960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, S4600, 3 DWPD, 5256 TBW | 400-ASYL (EOS) | |
| 960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW | 400-BDSI | |
| 960GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 5256 TBW | 400-BCQN | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW | 400-BEPD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASGE (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW | 400-ASFZ | |
| 1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, | 400-BDSU | |
| Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 | 400-BCVC | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCOM | |
| 1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW | 400-BEQI | |
| 1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 | 400-BCMJ | |
| 1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5 ″, ISE, Samsung, PM883a, PE / PV | 345-BBHN | |
| 3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW | 400-ASGI | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW | 400-AYZI | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW | 400-BDNK | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW | 400-BBQX | |
| 7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW | 345-BBBP | |
| Storage: All-Flash | Only SATA/SAS and NVMe SSDs | |
| 20 x 2.5″ SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions. | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ARXG (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASEO (EOS) | |
| 480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive | 400-BDSD (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW | 400-AZHC (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW | 400-AZII (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASFO (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASFI | |
| 960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, S4600, 3 DWPD, 5256 TBW | 400-ASYL (EOS) | |
| 960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW | 400-BDSI | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW | 400-BEPD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASGE (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW | 400-ASFZ | |
| 1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, | 400-BDSU | |
| 1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW | 400-BEQI | |
| 1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5 ″, ISE, Samsung, PM883a, PE / PV | 345-BBHN | |
| 3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW | 400-ASGI | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW | 400-AYZI | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW | 400-BDNK | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW | 400-BBQX | |
| 7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW | 345-BBBP | |
| 4 x NVMe SSDs | ||
| Dell 800GB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier | 400-AUMO (EOS) | |
| Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier | 400-AUMP (EOS) | |
| Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier | 400-BELT | |
| Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725b with Carrier | 400-BEFC | |
| Dell 3.2TB NVMe Mix Use Express Flash 2.5in SFF Drive U.2 P4610 | 400-BEDQ | |
| Dell 6.4TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier | 400-BELR | |
| Storage: Hybrid | Mix of SATA/SAS SSDs and HDDs | |
| 4, 6, or 8 x 2.5″ SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions. | ||
| 480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ARXG (EOS) | |
| 480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASEO (EOS) | |
| 480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive | 400-BDSD (EOS) | |
| 480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW | 400-BCQG (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW | 400-AZHC (EOS) | |
| 800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW | 400-AZII (EOS) | |
| 960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASFO (EOS) | |
| 960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV | 400-ASFI | |
| 960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW | 400-BDSI | |
| 960GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 5256 TBW | 400-BCQN | |
| 960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW | 400-BEPD | |
| 1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a | 400-ASGE (EOS) | |
| 1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW | 400-ASFZ | |
| 1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, | 400-BDSU | |
| Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 | 400-BCVC | |
| 1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW | 400-BCOM | |
| 1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW | 400-BEQI | |
| 1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 | 400-BCMJ | |
| 1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5 ″, ISE, Samsung, PM883a, PE / PV | 345-BBHN | |
| 3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW | 400-ASGI | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW | 400-AYZI | |
| 3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW | 400-BDNK | |
| 3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW | 400-BBQX | |
| 7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW | 345-BBBP | |
| 8, 10, 12, 14, 16, 18, or 20 x 2.5″ HDDsNote: The number of HDDs should be twice or more the number of SSDs. | ||
| 1TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive | 400-ASH | |
| 1.2TB 10K RPM Self-Encrypting SAS 12Gbps 512n 2.5in Hot-plug Hard Drive, FIPS140 | 400-ASHK | |
| 1.8TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive | 400-ARXC | |
| 2TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive | 400-ASHP | |
| 2.4TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive | 400-AVEZ | |
| 2.4TB 10K RPM Self-Encrypting SAS 12Gbps 512e 2.5in Hot-plug Hard Drive, FIPS140 | 400-AVHH | |
| Storage Controller | 1 x Storage Controller | |
| HBA330 Controller Adapter, Low Profile | 405-AANK | |
| HBA330 12Gbps SAS HBA Controller (NON-RAID), MiniCard | 405-AAJW | |
| RAID Option | In RAID | 780-BCDI |
| Component | Description | SKU |
| CPU | 2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU). | Various |
| Memory | DDR4-2666, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB | 370-ADND |
| DDR4-2666, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-DNF | |
| DDR4-2666, 1.2V, 64GB, LRDIMM12 x 64GB = 768GB 16 x 64GB = 1TB 24 x 64GB = 1.5TB Note: Select 2666MT/s LRDIMMs (SKU 370-ADNT) for memory DIMM type and speed option. | 370-DNA | |
| DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB Note:Select 2666MT/s LRDIMMs (SKU 370-ADNT) for memory DIMM type and speed option. For memory capacity higher than 768 GB and up to 1.5 TB per socket, order the Intel Skylake Xeon CPUs with suffix M. | 370-ADMX | |
| Component | Description | SKU |
| CPU | 2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU). | Various |
| Memory | DDR4-3200, 1.2V, 8 GB, RDIMM12 x 8 GB = 96 GB 16 x 8 GB = 128 GB 24 x 8 GB = 192 GB | 370-AEVO |
| DDR4-2933, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB | 370-AQF | |
| DDR4-3200, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB | 370-AEVQ | |
| DDR4-2933, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-AEQH | |
| DDR4-3200, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-EVN | |
| DDR4-2933, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB | 370-AQD | |
| DDR4-3200, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB | 370-EVP | |
| DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB | 370-ADMX | |
| Component | Description | SKU |
| FlexibleLOM Adapter | 1 x Flexible LAN on Motherboard (FLOM) adapter | |
| Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28, rNDC | 406-BBLG | |
| Intel X550 Quad Port 10GbE BASE-T, rNDC | 540-BBUY | |
| Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBUZ | |
| Intel Ethernet I350 QP 1Gb Network Daughter Card | 540-BBDD | |
| Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBBB | |
| Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC | 540-BBUK | |
| Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC | 540-BOOM | |
| Intel Ethernet I350 QP 1Gb Network Daughter Card | 540-BBB | |
| Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC | 555-BCKO | |
| PCIe Network Interface | 1x PCIe Network Interface | |
| Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28 Adapter, PCIe Full Height | 406-BBLE | |
| Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Full Height | 540-BBRO | |
| Intel X710 Dual Port 10GbE Direct Attach SFP+ Adapter, PCIe Full Height | 540-BBHP | |
| Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Low Profile, Customer Install | 540-BCCN | |
| Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Full Height | 540-BBDH | |
| Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Full Height | 540-BBUI | |
| Broadcom 57412 Dual Port 10GbE SFP+ Adapter, PCIe Full Height | 540-BBUH | |
| Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height | 540-BBCT | |
| Intel XXV710 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height | 540-BCDH | |
| Mellanox ConnectX-5 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Full Height | 540-BCNM | |
| Mellanox ConnectX-5 EX Dual Port 40 / 100GbE QSFP28 Adapter, PCIe Full Height | 540-BCIU | |
| Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height | 540-BBUJ | |
| Dual NIC Configuration | Note: Dual 10G Base-T NICs, 1 x 540-BBUY + 1 x 540-BBRO Dual 10G SFP+ NICs, 1 x 555-BCKO + 1 x 540-BBHP Dual 25G NICs, 1 x 406-BBLG + 1 x 406- BBLE | |
| Component | Description | SKU |
| GPU | 1 or 2 x GPUNote:For dual-GPU configuration, a combination of same GPUs is supported. Use the riser kit SKU 330-BBHH (Riser Config 4, 3 x 8, 4 x 16 slots, Double-Wide GPU compatible). Order a Heatsink and Install Kit for GPU Configuration; SKU 412-AAJK for M10 GPU and SKU 750-AAXX for P40 GPU. The GPU SKUs 490-BFRQ and 490-BFSG are supported with ESXi hypervisors. Starting from AOS 5.19, they are also supported with AHV. | |
| NVIDIA Tesla M10 GPU, Requires GRID 2.0 SW for VDI Function | 489-BBCG | |
| NVIDIA Tesla P40 24GB GPU (Single/Dual GPU) | 489-BBCN | |
| Dell 16GB NVIDIA Tesla T4 GPU Graphic Card | 490-BEYM | |
| NVIDIA® Tesla ™ V100 32GB, Passive, Double Wide, Full Height GPU | 490-BENY | |
| NVIDIA Tesla V100S 32GB, 250W, Passive, Double Wide, Full Height GPU | 490-BFRR | |
| NVIDIA® Tesla ™ V100 16GB, Passive, Double Wide, Full Height GPU | 490-BEDZ | |
| NVIDIA Quadro RTX 6000 24GB, 250W, Dual Slot, PCIe x16 Passive Cooled, Full Height GPU | 490-BFRQ | |
| NVIDIA Quadro RTX 8000 48 GB, 250W, Dual Slot, PCIe x16 Passive Cooled, Full Height GPU | 490-BFSG |
Nutanix Dell PowerEdge R630 10 SFF
R630 10 SFF Hardware Compatibility
| Component | Description | SKU |
|---|---|---|
| Chassis | Use cases:Analytics and Big Data Remote Office/Branch Office End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported. | |
| PowerEdge R630 ServerNodes per chassis: 1 | 210-ACXS | |
| 1 RU Chassis with up to 10, 2.5″ Hard Drives, 3 PCIe SlotsNodes per chassis: 1 | 321-BBKM | |
| boot drive | 1 x 64 GB Solid State SATA-DOM Boot DriveNote: The following hypervisors are supported: VMware ESXi 6.0u2 and Nutanix AHV | 400-AOQL |
| Power Supply | 2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1 + 1), 1100W | 450-ADWM |
| Embedded Systems Management | iDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise | 385-BBHO |
| Component | Description | SKU |
| Storage: Hybrid | Mix of SATA SSDs and HDDs | |
| 2 x 2.5 ″ SATA SSDs | ||
| 480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMID | |
| 800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIFQ | |
| 960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHE | |
| 1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIGF | |
| 1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHH | |
| 4, 6, or 8 x 2.5″ HDDs | ||
| 1TB 7.2K RPM Near-Line SAS 2.5in Hot-plug Hard Drive | 400-STUDENT | |
| 2TB 7.2K RPM NLSAS 512n 2.5in Hot-plug Hard Drive | 400-AMUC | |
| Storage: All-Flash | Only SATA/SAS SSDs | |
| 2 or 10 x 2.5″ SATA/SAS SSDs | ||
| 480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMID | |
| 800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIFQ | |
| 960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHE | |
| 1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIGF | |
| 1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHH | |
| 3.84TB Solid State Drive Serial Attached SCSI (SAS) Read Intensive 12Gbps 512e 2.5in Hot-plug Drive – PM1633a | 400-AQNT | |
| RAID Option | No RAID for HBA330/H330/H730/H730P (Inc Flex Bay) w/ SATADOMNote: This description does not indicate the list of supported controllers. Nutanix supports only HBA330 12Gbps SAS HBA Controller in R630 10 SFF. | 780-BCCZ |
| Storage Controller | 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard | 405-YYYY |
| Component | Description | SKU |
| CPU | 2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higherNote: The specified processor is the lowest supported processor. Higher processors are also supported. | Various |
| Memory | DDR4-2400, 1.2V, 16GB, RDIMM8 x 16GB = 128GB 16 x 16GB = 256GB | 370-ACNX |
| DDR4-2400, 1.2V, 32 GB, RDIMM8 x 32 GB = 256 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-ACNS | |
| DDR4-2400, 1.2V, 64 GB, LRDIMM8 x 64 GB = 512 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Use the memory options 370-AAIP (Memory Configuration Type: Performance Optimized) and 370 -ACPG (Memory DIMM Type and Speed: 2400MT/s LRDIMMs) for selecting the 64 GB DIMM in Dell Configurator. | 370-ACNV | |
| Component | Description | SKU |
| Network Interface | 1x Network Interface | |
| Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBBB | |
| Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height | 540-BBCT | |
| Dual NIC Configuration | Note: Dual 10G NICs, 1 x 540-BBBB + 1 x 540-BBCT |
Nutanix Dell PowerEdge R730xd 12 LFF
R730xd 12 LFF Hardware Compatibility
| Component | Description | SKU |
|---|---|---|
| Chassis | Use cases:Analytics and Big Data Backup and Disaster Recovery Files and Objects Private Cloud Test and Development End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported. | |
| PowerEdge R730xd ServerNodes per chassis: 1 | 210-ADBC | |
| 2 RU Chassis with up to 12, 3.5″ Hard DrivesNodes per chassis: 1 | 350-BEU | |
| boot drive | 1 x 64 GB Solid State SATA-DOM Boot DriveNote: The following hypervisors are supported: VMware ESXi 6.0u2 and Nutanix AHV | 400-AOQL |
| Power Supply | 2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1 + 1), 1100W | 450-ADWM |
| Embedded Systems Management | iDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise | 385-BBHO |
| Component | Description | SKU |
| Storage: Hybrid | Mix of SATA SSDs and HDDs | |
| 2 or 4 x 3.5 ″ SATA SSDs | ||
| 480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863 | 400-AMHB | |
| 800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610 | 400-AGG | |
| 960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863 | 400-FRIEND | |
| 1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610 | 400-AIFO | |
| 1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive 3.5in HYB CARR, SM863 | 400-AMIX | |
| 8 or 10 x 3.5″ HDDs | ||
| 2TB 7.2K RPM NLSAS 512n 3.5in Hot-plug Hybrid Carrier Hard Drive | 400-ALPB | |
| 4TB 7.2K RPM NLSAS 512n 3.5in Hot-plug Hybrid Carrier Hard Drive | 400-ALOV | |
| 4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive | 400-ALNY | |
| 8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard DriveNote: AOS 5.11 and above supports a maximum of 120TB storage per node. | 400-AMPP | |
| 8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Drive | 400-AMPG | |
| Storage: All-Flash | Only SATA SSDs | |
| 12 x 3.5 ″ SATA SSDs | ||
| 480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863 | 400-AMHB | |
| 800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610 | 400-AGG | |
| 960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863 | 400-FRIEND | |
| 1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610 | 400-AIFO | |
| 1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive 3.5in HYB CARR, SM863 | 400-AMIX | |
| RAID Option | No RAID for HBA330/H330/H730/H730P (Inc Flex Bay) w/ SATADOMNote: This description does not indicate the list of supported controllers. Nutanix supports only HBA330 12Gbps SAS HBA Controller in R730xd 12 LFF. | 780-BCCT |
| Storage Controller | 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard | 405-YYYY |
| Component | Description | SKU |
| CPU | 2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher.Note: The specified processor is the lowest supported processor. Higher processors are also supported. | Various |
| Memory | DDR4-2400, 1.2V, 16GB, RDIMM8 x 16GB = 128GB 16 x 16GB = 256GB | 370-ACNX |
| DDR4-2400, 1.2V, 32 GB, RDIMM8 x 32 GB = 256 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-ACNS | |
| DDR4-2400, 1.2V, 64 GB, LRDIMM8 x 64 GB = 512 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Use the memory options 370-AAIP (Memory Configuration Type: Performance Optimized) and 370 -ACPG (Memory DIMM Type and Speed: 2400MT/s LRDIMMs) for selecting the 64 GB DIMM in Dell Configurator. | 370-ACNV | |
| Component | Description | SKU |
| Network Interface | 1x Network Interface | |
| Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBBB | |
| Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height | 540-BBCT | |
| Dual NIC Configuration | Note: Dual 10G NICs, 1 x 540-BBBB + 1 x 540-BBCT |
Nutanix Dell PowerEdge R730xd 24 SFF
R730xd 24 SFF Hardware Compatibility
| Component | Description | SKU |
|---|---|---|
| Chassis | Use cases:Analytics and Big Data Database and Business Critical Apps Private Cloud Test and Development End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported. | |
| PowerEdge R730xd ServerNodes per chassis: 1 | 210-ADBC | |
| 2 RU Chassis with up to 24, 2.5″ Hard DrivesNodes per chassis: 1 | 350-BBFD | |
| boot drive | 1 x 64 GB Solid State SATA-DOM Boot DriveNote: The following hypervisors are supported: VMware ESXi 6.0u2 and Nutanix AHV | 400-AOQL |
| Power Supply | 2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1 + 1), 1100W | 450-ADWM |
| Embedded Systems Management | iDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise | 385-BBHO |
| Component | Description | SKU |
| Storage: Hybrid | Mix of SATA/SAS SSDs and HDDs | |
| 4 x 2.5″ SATA/SAS SSDs | ||
| 480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMID | |
| 800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIFQ | |
| 960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHE | |
| 1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIGF | |
| 1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHH | |
| 3.84TB Solid State Drive SAS RI 12Gbps 512e 2.5in Hot-plug Drive, PM1633a | 400-AQNF | |
| 20 x 2.5 ″ HDDs | ||
| 1TB 7.2K RPM Near-Line SAS 2.5in Hot-plug Hard Drive | 400-STUDENT | |
| 2TB 7.2K RPM NLSAS 512n 2.5in Hot-plug Hard Drive | 400-AMUC | |
| Storage: All-Flash | Only SATA/SAS SSDs | |
| 24 x 2.5″ SATA/SAS SSDs | ||
| 480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMID | |
| 800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIFQ | |
| 960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHE | |
| 1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIGF | |
| 1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHH | |
| 3.84TB Solid State Drive SAS RI 12Gbps 512e 2.5in Hot-plug Drive, PM1633a | 400-AQNF | |
| RAID Option | No RAID for HBA330/H330/H730/H730P (Inc Flex Bay) w/ SATADOMNote: This description does not indicate the list of supported controllers. Nutanix supports only HBA330 12Gbps SAS HBA Controller in R730xd 24 SFF. | 780-BCCT |
| Storage Controller | 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard | 405-YYYY |
| Component | Description | SKU |
| CPU | 2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher.Note: The specified processor is the lowest supported processor. Higher processors are also supported. | Various |
| Memory | DDR4-2400, 1.2V, 16GB, RDIMM8 x 16GB = 128GB 16 x 16GB = 256GB | 370-ACNX |
| DDR4-2400, 1.2V, 32 GB, RDIMM8 x 32 GB = 256 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-ACNS | |
| DDR4-2400, 1.2V, 64 GB, LRDIMM8 x 64 GB = 512 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Use the memory options 370-AAIP (Memory Configuration Type: Performance Optimized) and 370 -ACPG (Memory DIMM Type and Speed: 2400MT/s LRDIMMs) for selecting the 64 GB DIMM in Dell Configurator. | 370-ACNV | |
| Component | Description | SKU |
| Network Interface | 1x Network Interface | |
| Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBBB | |
| Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height | 540-BBCT | |
| Dual NIC Configuration | Note: Dual 10G NICs, 1 x 540-BBBB + 1 x 540-BBCT |
Nutanix Dell PowerEdge R730 16 SFF
R730 16 SFF Hardware Compatibility
| Component | Description | SKU |
|---|---|---|
| Chassis | Use cases:Analytics and Big Data Database and Business Critical Apps Note: Only Legacy BIOS is supported. | |
| PowerEdge R730 ServerNodes per chassis: 1 | 210-ACXU | |
| 2 RU Chassis with up to 16, 2.5″ Hard DrivesNodes per chassis: 1 | 350-BBIL | |
| boot drive | 1 x 64 GB Solid State SATA-DOM Boot DriveNote: The following hypervisors are supported: VMware ESXi 6.0u2 and Nutanix AHV | 400-AOQL |
| Power Supply | 2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1 + 1), 1100W | 450-ADWM |
| Embedded Systems Management | iDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise | 385-BBHO |
| Component | Description | SKU |
| Storage: Hybrid | Mix of SATA SSDs and HDDs | |
| 2 or 4 x 2.5 ″ SATA SSDs | ||
| 480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMID | |
| 800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIFQ | |
| 960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHE | |
| 1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIGF | |
| 1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHH | |
| 4, 6, 8, 12, or 14 x 2.5″ HDDsNote: The HDDs need to be twice or more the number of SSDs. | ||
| 1TB 7.2K RPM Near-Line SAS 2.5in Hot-plug Hard Drive | 400-STUDENT | |
| 2TB 7.2K RPM NLSAS 512n 2.5in Hot-plug Hard Drive | 400-AMUC | |
| Storage: All-Flash | Only SATA SSDs | |
| 16 x 2.5 ″ SATA SSDs | ||
| 480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMID | |
| 800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIFQ | |
| 960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHE | |
| 1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 | 400-AIGF | |
| 1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 | 400-AMHH | |
| RAID Option | No RAID for HBA330 (1-16 HDDs or SSDs) SATADOM | 780-BCCS |
| Storage Controller | 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard | 405-YYYY |
| Component | Description | SKU |
| CPU | 2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher.Note: The specified processor is the lowest supported processor. Higher processors are also supported. | Various |
| Memory | DDR4-2400, 1.2V, 16GB, RDIMM8 x 16GB = 128GB 16 x 16GB = 256GB | 370-ACNX |
| DDR4-2400, 1.2V, 32 GB, RDIMM8 x 32 GB = 256 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB | 370-ACNS | |
| DDR4-2400, 1.2V, 64 GB, LRDIMM8 x 64 GB = 512 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Use the memory options 370-AAIP (Memory Configuration Type: Performance Optimized) and 370 -ACPG (Memory DIMM Type and Speed: 2400MT/s LRDIMMs) for selecting the 64 GB DIMM in Dell Configurator. | 370-ACNV | |
| Component | Description | SKU |
| Network Interface | 1x Network Interface | |
| Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC | 540-BBBB | |
| Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height | 540-BBCT | |
| Dual NIC Configuration | Note: Dual 10G NICs, 1 x 540-BBBB + 1 x 540-BBCT |
Some segments of the economy that we help
Previous
Next
Some segments of the economy that we help
Previous
Next
Third-party maintenance for Nutanix End-of-Life (EOL) and Nutanix End-of-Service-Life (EOSL)
A DC Parts made an analysis on more than 250 customer contracts that use storage, servers, networks and tapes and showed us that 40-60% of the equipment of these customers operate beyond the end dates of support.
There are simple options for you to reduce your expenses and feel more confident about your IT infrastructure. When you choose a custom solution to extend the life of your IT equipment, you can make big savings.
How can we help:
We offer our customers a unique assessment to help analyze their OEM support contracts and understand exactly which devices can be supported in the most affordable way, without compromising their performance.
Nutanix hardware support
Support services DC Parts provide support for Nutanix hardware. We work to match the right approach with the right equipment to meet your Nutanix hardware support needs.
With a highly trained team of certified engineers ready to troubleshoot any Nutanix hardware issues, DC Parts is uniquely qualified to serve you. If you would like to speak with a representative about purchasing support on Nutanix hardware, please contact us.
A DC Parts helps companies of all sizes better manage their IT data centers by providing third-party support services to leading equipment manufacturers, including: Dell, IBM, HPE, netapp, oracle sun, Cisco and more.
With support DC Parts, we manage all your hardware, between the manufacturers through a link. Support from DC Parts offers flexible service level agreements, certified engineering support teams and dedicated customer service representatives.
Extend the life and value of your IT assets. Contact Support DC Parts immediately.
Need support?
Contact us, we will contact you as soon as possible
