Hardware support and maintenance Nutanix Dell PowerEdge



The Nutanix hardware you have in your IT infrastructure can still provide the functionality, flexibility and practicality for the vast majority of organizations today. The ability to add additional memory (if not already specified at time of purchase) and CPU provides customers with a variety of options to upgrade their host servers (virtualized environments) to continue to deliver the required performance beyond the manufacturers' end-of-life dates. These potential upgrade options mean that customers do not have to constantly look for new server solutions at the end of a 3 or 5 year internal lifecycle program because the servers are no longer fit for purpose.



Nutanix hardware from partners

Outsourcing Nutanix Hardware Maintenance



DC Parts provides organizations with a viable and sustainable alternative option to extend the life of their Nutanix hardware after 'end of life' or 'end of life support' announcements and is able to provide recommended hardware upgrade options , which includes and incorporates complete installation and configuration work performed by experienced technical field engineers. Our ability to continue to provide an alternative server maintenance support service for Nutanix haedware further assists organizations by providing a cost-effective solution for mission-critical Nutanix hardware. This solution significantly reduces your total cost of ownership and also generates a greater return on your initial capital expenditure on IT server hardware.

DC Parts offers a flexible approach for organizations looking to partially or fully integrate with their organization's maintenance and support services for current or historical server systems. These service levels range from NBD (Next Business Day) to a 24/7 response. Our maintenance and support services range from parts only to telephone and remote support. Our service level pages describe these and other services in detail.

Get in touch with us to see if we can provide the guarantees you need, especially to explore an alternative maintenance support service.

Asset Residual Value for Your Nutanix Hardware



Our exclusive maintenance and support service for Nutanix hardware can provide you with the potential to customize a cost-neutral maintenance contract for Nutanix hardware that is now post-warranty, end of life or end of life (EOL / EOSL). Our service allows customers with Nutanix hardware to have multiple stages in a lifecycle program, while providing extended maintenance support regardless of the need for 3,6,9 or even 12 months of support, thus effectively creating a solution neutral in terms of cost.



Cost reduction in your contract



We allow a cost neutral maintenance solution to be provided through the residual value on your Nutanix hardware that we would remove at the end of the agreed maintenance support term. As well as services for secure deactivation and elimination of data according to internal compliance requirements will also be part of the discussion of the hardware lifecycle services program.

If you don't need a support service, our maintenance service can still benefit you. So we can provide a residual value quote for your IT server and storage hardware and discuss the process of deactivating and deleting data, allowing you to get a much higher return on your initial capital investment. There is no obligation to obtain a quote from DC Parts, but it does allow you to explore whether this service can be viable and beneficial for you.

Hyper-converged infrastructure (HCI) is becoming a significant service platform in the datacenter, and with good reason. Processing abstraction, storage and network resources to create a fully software-defined network datacenter is the logical progression of the decade of virtualization trend. Companies like Nutanix are leading the way, enabling IT departments to create and expand application environments by simply adding common off-the-shelf servers. Eliminating the expense and complexity of deploying and managing a datacenter full of disparate devices with a mix of management interfaces plus multiple networking and storage protocols make it easier to deploy and support an on-premises cloud.

As a leading provider of enterprise servers, the Dell EMC product line is a recognized standard when it comes to data center deployments. The PowerEdge platform is an ideal building block for a Nutanix private cloud. Dell EMC's partnership with Nutanix extends to XC series appliances – one and two rack unit PowerEdge servers specifically certified to support the Nutanix HCI solution.

DC Parts has extensive knowledge of Dell PowerEdge hardware and our team has years of experience with PowerEdge systems. DC Parts can customize a support package to meet your organization's immediate or long-term needs, from short-term 9 to 5 contracts to annual maintenance packages 24 hours a day, 7 days a week. DC Parts consultants work with customers to ensure they get the guarantees they need at a cost that suits their budget. Our flexibility, together with our comprehensive understanding of the PowerEdge line, allows DC Parts to help organizations maximize investment in their IT infrastructure.



Benefits of maintenance support DC Parts in hardware Nutanix com Dell PowerEdge



  • Technical diagnostics and repair of Dell PowerEdge servers
  • Level 3 engineer assigned to an account
  • Global service availability
  • Maintenance support for current and end-of-life Dell equipment
  • Pro-rata support and co-termination dates
  • Site audits / surveys
  • Data / platform migration
  • IT decommissioning
  • Data erasure
  • Highly experienced and specially trained technical field engineers
  • On-site spare parts cache
  • Various methods for generating a fault ticket ticket
  • Helpdesk assistance
  • Operating system and firmware recommendations
  • Professional services
    • Consulting
    • VMware
    • Hardware upgrades
  • Flexible short and long-term maintenance support contracts
  • Hardware rental
  • DMR (digital media retention)
  • Operational savings



End of support Nutanix with hardware Dell PowerEdge, but not DC Parts



Supported Models

R440 8SFF Hardware Compatibility

ComponentDescriptionSKU
Chassis2.5" Chassis with up to 8 Hot Plug Hard Drives Nodes per chassis: 1 Use cases: Analytics and Big Data Remote Office/Branch Office End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported.321-BCUV
boot drive1 x BOSS controller card + with 2 M.2 Sticks 240G (RAID 1), LP403-BBPZ
Power Supply1 x Dual, Hot Plug, Redundant Power Supply (1 + 1), 550W450-AGOY
Embedded Systems ManagementiDRAC9 Basic385-BBLD
iDRAC PasswordiDRAC, Factory Generated Password379-BCSF
ComponentDescriptionSKU
Storage: All-FlashOnly SAS SSDs
2, 4, 6, or 8 x 2.5" SAS SSDs
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASFI
960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW400-BEPD
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive,400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883400-BCVC
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW400-BCOM
1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5400-BCMJ
1.92TB SATA RI SSD (1 DWPD), 512e, 6Gbps, 2.5", ISE, Samsung, PM883a, PE/PV345-BBHN
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW400-AYZI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW345-BBBP
Storage Controller1 x Storage Controller
HBA330 Controller Adapter, Low Profile405-AANK
HBA330 12Gbps SAS HBA Controller (NON-RAID), MiniCard405-AAJW
RAID OptionIn RAID780-BCDI
ComponentDescriptionSKU
CPU2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU).Various
MemoryNote: Order the memory configuration SKU 370-AAIP (Performance Optimized) along with the memory DIMMs.
DDR4-2666, 1.2V, 16GB, RDIMM 16x16GB = 256GB370-ADND
DDR4-2666, 1.2V, 32GB, RDIMM 16x32GB = 512GB370-ADNF
ComponentDescriptionSKU
PCIe Network Interface1 x Intel X710 Dual Port 10GbE SFP + Adapter, PCIe Low Profile555-BCKN

R640 10 SFF Hardware Compatibility

ComponentDescriptionSKU
ChassisUse cases:Analytics and Big Data Remote Office/Branch Office End-User Computing/Virtual Desktop Infrastructure Note:Only Legacy BIOS is supported. For chassis with NVMe support, order the chassis SKU 321-BCQQ.
PowerEdge R640 ServerNodes per chassis: 1210-AKWU
2.5 Chassis with up to 10 Hard Drives and 3PCIe slotsNodes per chassis: 1321-BCQL
2.5" Chassis with up to 10 Hard Drives, 8 NVMe Drives and 3PCIe Slots, 2CPU onlyNodes per chassis: 1321-BCQQ
boot drive1 x M.2 SSD
BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),LP403-BBPM
BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),LP403-BBPZ
BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),LP403-BCHI
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP403-BBUU
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP403-BCHH
Power Supply1 x Dual, Hot-plug power supply
750W Dual, Hot-plug, Redundant Power Supply (1+1)450-ADWS
Dual, Hot-plug, Redundant Power Supply (1+1), 1100W450-ADWM
Embedded Systems ManagementiDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise385-BBKT
iDRAC PasswordiDRAC, Legacy Password379-BCSG
ComponentDescriptionSKU
Storage: All-FlashOnly SATA/SAS SSDs
2, 4, 6, 8, or 10 x 2.5" SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions.
480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ARXG (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASEO (EOS)
480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive400-BDSD (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW400-BCQG (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW400-AZHC (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW400-AZII (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASFO (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASFI
960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, S4600, 3 DWPD, 5256 TBW400-ASYL (EOS)
960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW400-BEPD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASGE (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive,400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883400-BCVC
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW400-BCOM
1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5400-BCMJ
1.92TB SATA RI SSD (1 DWPD), 512e, 6Gbps, 2.5", ISE, Samsung, PM883a, PE/PV345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW345-BBBP
Storage: All-FlashOnly SATA/SAS and NVMe SSDs
6 or 8 x 2.5" SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions.
480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ARXG (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASEO (EOS)
480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive400-BDSD (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW400-AZHC (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW400-AZII (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASFO (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASFI
960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW400-BEPD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASGE (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive,400-BDSU
1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW400-BEQI
1.92TB SATA RI SSD (1 DWPD), 512e, 6Gbps, 2.5", ISE, Samsung, PM883a, PE/PV345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW345-BBBP
2 or 4 x 2.5" NVMe SSDs
Dell 800GB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier400-AUMO (EOS)
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier400-AUMP (EOS)
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier400-BELT
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725b with Carrier400-BEFC
Dell 3.2TB NVMe Mix Use Express Flash 2.5in SFF Drive U.2 P4610400-BEDQ
Dell 6.4TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier400-BELR
Storage: HybridMix of SATA/SAS SSDs and HDDs
2 x 2.5" SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions.
480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ARXG (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASEO (EOS)
480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive400-BDSD (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW400-BCQG (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW400-AZHC (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW400-AZII (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASFO (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASFI
960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW400-BEPD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASGE (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive,400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883400-BCVC
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW400-BCOM
1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5400-BCMJ
1.92TB SATA RI SSD (1 DWPD), 512e, 6Gbps, 2.5", ISE, Samsung, PM883a, PE/PV345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW345-BBBP
4, 6, or 8 x 2.5" HDDs
1TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive400-ASH
1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive400-ASHI
1.2TB 10K RPM Self-Encrypting SAS 12Gbps 512n 2.5in Hot-plug Hard Drive, FIPS140400-ASHK
1.8TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive400-ARXC
2TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive400-ASHP
2.4TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive400-AVEZ
2.4TB 10K RPM Self-Encrypting SAS 12Gbps 512e 2.5in Hot-plug Hard Drive, FIPS140400-AVHH
Storage Controller1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard405-YYYY
RAID OptionIn RAID780-BCDI
ComponentDescriptionSKU
CPU2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU).Various
MemoryNote: Order the memory configuration SKU 370-AAIP (Performance Optimized) along with the memory DIMMs.
DDR4-2666, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB370-ADND
DDR4-2666, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-ADNF
DDR4-2666, 1.2V, 64GB, LRDIMM12 x 64GB = 768GB 16 x 64GB = 1TB 24 x 64GB = 1.5TB Note: Select 2666MT/s LRDIMMs (SKU 370-ADNT) for memory DIMM type and speed option.370-ADNH
DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB Note:Select 2666MT/s LRDIMMs (SKU 370-ADNT) for Memory DIMM Type and Speed option. For memory capacity higher than 768 GB and up to 1.5 TB per socket, order the Intel Skylake Xeon CPUs with suffix M.370-ADMX
ComponentDescriptionSKU
CPU2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU).Various
MemoryNote: Order the memory configuration SKU 370-AAIP (Performance Optimized) along with the memory DIMMs.
DDR4-3200, 1.2V, 8 GB, RDIMM12 x 8 GB = 96 GB 16 x 8 GB = 128 GB 24 x 8 GB = 192 GB370-AEVO
DDR4-2933, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB370-AQF
DDR4-3200, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB370-AEVQ
DDR4-2933, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-AEQH
DDR4-3200, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-EVN
DDR4-2933, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB370-AQD
DDR4-3200, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB370-EVP
DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB370-ADMX
ComponentDescriptionSKU
FlexibleLOM Adapter1 x Flexible LAN on Motherboard (FLOM) adapter
Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28, rNDC406-BBLG
Intel X550 Quad Port 10GbE BASE-T, rNDC540-BBUY
Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC540-BBUZ
Intel Ethernet I350 QP 1Gb Network Daughter Card540-BBB
Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC540-BBUK
Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC540-BOOM
Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC555-BCKO
PCIe Network Interface1x PCIe Network Interface
Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile406-BBLD
Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile540-BBRL
Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Low Profile, Customer Install540-BCCN
Intel Ethernet i350 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile540-BBCZ
Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile540-BBVK
Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Low Profile540-BBDB
Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile540-BBVJ
Intel XXV710 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile540-BCCM
Broadcom 57412 Dual Port 10GbE SFP + Adapter, PCIe Low Profile540-BBVI
Mellanox ConnectX-5 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile540-BCMQ
Broadcom 57412 Dual Port 10GbE SFP+ & 5720 Dual Port 1GbE BASE-T rNDC540-BUL
Intel X710 Dual Port 10GbE SFP+ Adapter, PCIe Low Profile555-BCKN
Dual NIC ConfigurationNote: Dual 10G Base-T NICs, 1 x 540-BBUY + 1 x 540-BBRL Dual 10G SFP+ NICs, 1 x 555-BCKO + 1 x 555-BCKN Dual 25G NICs, 1 x 406-BBLG + 1 x 406- BBLD

R640 4 LFF Hardware Compatibility



Qualification date: March 2018



Component Description SKU
Chassis Use cases: Remote Office/Branch Office

PowerEdge R640 Server

Nodes per chassis: 1

210-AKWU
3.5 Chassis with up to 4 Hard Drives and 3PCIe slots

Nodes per chassis: 1

321-BCQF
boot drive 1 x M.2 SSD
BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),LP 403-BBPM
BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),LP 403-BBPZ
BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),LP 403-BCHI
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP 403-BBUU
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP 403-BCHH
Power Supply 2x Hot plug power supply
750W Dual, Hot-plug, Redundant Power Supply (1+1) 450-ADWS
Dual, Hot-plug, Redundant Power Supply (1+1), 1100W 450-ADWM
Embedded Systems Management iDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise 385-BBKT
iDRAC Password iDRAC, Legacy Password 379-BCSG



Table. Storage
Component Description SKU
Storage: All-Flash Only SATA/SAS SSDs
2 or 4 x 3.5″ SATA/SAS SSDs

480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a 400-ASES  (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASEP  (EOS)
480GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSV  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQD  (EOS)
800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW 400-AZFZ  (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASFP  (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASFJ  (EOS)
960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, S4600, 3DWPD, 5256TBW 400-ASYM  (EOS)
960GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSW
960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW 400-BCQF
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V, 3 DWPD, 5256 TBW 400-BEQD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASGF  (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASGB  (EOS)
1.92TB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSY
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW 400-BCPF
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW 400-BEPQ
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW 400-BEQT
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW 400-AYYB
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008TBW 400-BDMN
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW 400-BBQ
7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW 345-BBCH
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
2 x 3.5″ SATA/SAS SSDs

480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a 400-ASES  (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASEP  (EOS)
480GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSV  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQD  (EOS)
800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW 400-AZFZ  (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASFP  (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASFJ  (EOS)
960GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSW
960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW 400-BCQF
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V, 3 DWPD, 5256 TBW 400-BEQD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASGF  (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASGB  (EOS)
1.92TB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSY
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW 400-BCPF
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW 400-BEPQ
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW 400-BEQT
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW 400-AYYB
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008TBW 400-BDMN
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW 400-BBQ
7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW 345-BBCH
2 x 3.5 ″ HDDs
1TB 7.2K RPM NLSAS 12Gbps 512n 2.5in Hot-plug Hard Drive, 3.5in HYB CARR 400-ASKF
2TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-Plug Hard Drive 400-ASH
4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive 400-ASHY
8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive 400-ASIB
8TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 400-ASID
8 TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive 400-ASUG
12TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive 400-AWIP
12TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 400-AXN
12TB 7.2K SAS 12Gbps 512e 3.5in Hot-Plug Hard Drive 400-BEJR
Storage Controller 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard 405-YYYY
RAID Option In RAID 780-BCDI



Table. Skylake: CPU and Memory
Component Description SKU
CPU 1 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU). Various
Memory DDR4-2666, 1.2V, 16GB, RDIMM

  • 6x16GB = 96GB
  • 12x16GB = 192GB
370-ADND
DDR4-2666, 1.2V, 32GB, RDIMM

  • 6x32GB = 192GB
  • 12x32GB = 384GB
370-ADNF
DDR4-2666, 1.2V, 64GB, LRDIMM

  • 6x64GB = 384GB
  • 12x64GB = 768GB
370-ADNH
DDR4-2667, 1.2V, 128GB, LRDIMM

  • 6x128GB = 768GB
  • 12x128GB = 1.5TB
370-ADMX



Table. Cascade Lake and Cascade Lake Refresh: CPU and Memory
Component Description SKU
CPU 1 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU). Various
Memory DDR4-3200, 1.2V, 8GB, RDIMM

  • 6x8GB = 48GB
  • 12x8GB = 96GB
370-AEVO
DDR4-2933, 1.2V, 16GB, RDIMM

  • 6x16GB = 96GB
  • 12x16GB = 192GB
370-AQF
DDR4-3200, 1.2V, 16GB, RDIMM

  • 6x16GB = 96GB
  • 12x16GB = 192GB
370-AEVQ
DDR4-2933, 1.2V, 32GB, RDIMM

  • 6x32GB = 192GB
  • 12x32GB = 384GB
370-AEQH
DDR4-3200, 1.2V, 32GB, RDIMM

  • 6x32GB = 192GB
  • 12x32GB = 384GB
370-EVN
DDR4-2933, 1.2V, 64GB, RDIMM

  • 6x64GB = 384GB
  • 12x64GB = 768GB
370-AQD
DDR4-3200, 1.2V, 64GB, RDIMM

  • 6x64GB = 384GB
  • 12x64GB = 768GB
370-EVP
DDR4-2667, 1.2V, 128GB, LRDIMM

  • 6x128GB = 768GB
  • 12x128GB = 1.5TB
370-ADMX



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 x Flexible LAN on Motherboard (FLOM) adapter
Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28, rNDC 406-BBLG
Intel X550 Quad Port 10GbE BASE-T, rNDC 540-BBUY
Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC 540-BBUZ
Intel Ethernet I350 QP 1Gb Network Daughter Card 540-BBB
Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC 540-BBUK
Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC 540-BOOM
Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC 555-BCKO
PCIe Network Interface 1x PCIe Network Interface
Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile 406-BBLD
Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile 540-BBRL
Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Full Height, Customer Install 540-BCDG
Intel Ethernet i350 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile 540-BBCZ
Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile 540-BBVK
Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Low Profile 540-BBDB
Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile 540-BBVJ
Intel XXV710 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile 540-BCCM
Broadcom 57412 Dual Port 10GbE SFP + Adapter, PCIe Low Profile 540-BBVI
Mellanox ConnectX-5 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Low Profile 540-BCMQ
Broadcom 57412 Dual Port 10GbE SFP+ & 5720 Dual Port 1GbE BASE-T rNDC 540-BUL
Intel X710 Dual Port 10GbE SFP+ Adapter, PCIe Low Profile 555-BCKN
Dual NIC Configuration

R740xd 12 LFF Hardware Compatibility

ComponentDescriptionSKU
ChassisUse cases:Analytics and Big Data Backup and Disaster Recovery Files and Objects Private Cloud Test and Development End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported.
PowerEdge R740xd ServerNodes per chassis: 1210-AKZR
Chassis with Up to 12 x 3.5 Hard Drives for 2CPU ConfigurationNodes per chassis: 1321-BCPU
boot drive1 x M.2 SSD
BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),FH403-BBPJ
BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),FH403-BBPT
BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),FH403-BCHP
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH403-BBSV
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH403-BCHJ
Power Supply2x Hot plug power supply
750W Dual, Hot-plug, Redundant Power Supply (1+1)450-ADWS
Dual, Hot-plug, Redundant Power Supply (1+1), 1100W450-ADWM
Dual, Hot-plug, Redundant Power Supply (1 + 1), 1600W, 250 Volt Power Cord Required for Use450-AFMQ
Embedded Systems ManagementiDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise385-BBKT
iDRAC PasswordiDRAC, Legacy Password379-BCSG
ComponentDescriptionSKU
Storage: All-FlashOnly SATA/SAS SSDs
4, 6, 8, 10, or 12 x 3.5" SATA/SAS SSDsNote: The SSD SKUs 400-AYYB, 400-BDMN, 400-BDSW, 400-BDSY, and 400-BDSV are supported with Foundation 4.3.4 and higher versions.
480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a400-ASES (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV400-ASEP (EOS)
480GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive400-BDSV (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW400-BCQG (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW400-BCQD (EOS)
800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW400-AZFZ (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a400-ASFP (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV400-ASFJ (EOS)
960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, S4600, 3DWPD, 5256TBW400-ASYM (EOS)
960GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive400-BDSW
960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW400-BCQF
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V, 3 DWPD, 5256 TBW400-BEQD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a400-ASGF (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV400-ASGB (EOS)
1.92TB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive400-BDSY
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW400-BCOM
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW400-BCPF
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW400-BEPQ
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW400-BEQT
3.84TB SSD SAS RI 12Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, PM1633a400-ASGK (EOS)
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW400-AYYB
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008TBW400-BDMN
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW400-BBQ
7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW345-BBCH
Storage: HybridMix of SATA/SAS SSDs and HDDs
2 or 4 x 3.5" SATA/SAS SSDsNote: The SSD SKUs 400-AYYB, 400-BDMN, 400-BDSW, 400-BDSY, and 400-BDSV are supported with Foundation 4.3.4 and higher versions.
480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a400-ASES (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV400-ASEP (EOS)
480GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive400-BDSV (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW400-BCQG (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW400-BCQD (EOS)
800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW400-AZFZ (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a400-ASFP (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV400-ASFJ (EOS)
960GB SSD Mixed SATA Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive400-BDSW
960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW400-BCQF
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V, 3 DWPD, 5256 TBW400-BEQD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a400-ASGF (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV400-ASGB (EOS)
1.92TB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive400-BDSY
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW400-BCOM
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW400-BCPF
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW400-BEPQ
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3DWPD 10512TBW400-BEQT
3.84TB SSD SAS RI 12Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, PM1633a400-ASGK (EOS)
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive, 3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW400-AYYB
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008TBW400-BDMN
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW400-BBQ
7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW345-BBCH
4, 6, 8, or 10 x 3.5" HDDsNote: The HDDs need to be twice or more the number of SSDs.
1TB 7.2K RPM NLSAS 12Gbps 512n 2.5in Hot-plug Hard Drive, 3.5in HYB CARR400-ASKF
2TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-Plug Hard Drive400-ASH
2.4TB 10000rpm Sas-12gbps 512e 256mb Buffer 2.5inch (in 3.5inch Hybrid Carrier)400-ANTE
4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive400-ASHY
4TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive, FIPS140400-ASHZ
8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive400-ASIB
8TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140400-ASID
8 TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive400-ASUG
12TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140400-AXN
12TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive400-AWIP
12TB 7.2K SAS 12Gbps 512e 3.5in Hot-Plug Hard Drive400-BEJR
Storage Controller1 x Storage Controller
HBA330 Controller Adapter, Low Profile405-AANK
HBA330 12Gbps SAS HBA Controller (NON-RAID), MiniCard405-AAJW
RAID OptionIn RAID780-BCDI
ComponentDescriptionSKU
CPU2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU).Various
MemoryDDR4-2666, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB370-ADND
DDR4-2666, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-ADNF
DDR4-2666, 1.2V, 64 GB, LRDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Select 2666MT/s LRDIMMs (SKU 370-ADNT) for Memory DIMM Type and Speed option.370-ADNH
DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB Note:Select 2666MT/s LRDIMMs (SKU 370-ADNT) for Memory DIMM Type and Speed option. For memory capacity higher than 768 GB and up to 1.5 TB per socket, order the Intel Skylake Xeon CPUs with suffix M.370-ADMX
ComponentDescriptionSKU
CPU2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU).Various
MemoryDDR4-3200, 1.2V, 8 GB, RDIMM12 x 8 GB = 96 GB 16 x 8 GB = 128 GB 24 x 8 GB = 192 GB370-AEVO
DDR4-2933, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB370-AQF
DDR4-3200, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB370-AEVQ
DDR4-2933, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-AEQH
DDR4-3200, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-EVN
DDR4-2933, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB370-AQD
DDR4-3200, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB370-EVP
DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB370-ADMX
ComponentDescriptionSKU
FlexibleLOM Adapter1 x Flexible LAN on Motherboard (FLOM) adapter
Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28, rNDC406-BBLG
Intel X550 Quad Port 10GbE BASE-T, rNDC540-BBUY
Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC540-BBUZ
Intel Ethernet I350 QP 1Gb Network Daughter Card540-BBDD
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC540-BBBB
Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC540-BBUK
Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC540-BOOM
Intel Ethernet I350 QP 1Gb Network Daughter Card540-BBB
Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC555-BCKO
PCIe Network Interface1x PCIe Network Interface
Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28 Adapter, PCIe Full Height406-BBLE
Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Full Height540-BBRO
Intel X710 Dual Port 10GbE Direct Attach SFP+ Adapter, PCIe Full Height540-BBHP
Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Full Height, Customer Install540-BCDG
Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Full Height540-BBDH
Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Full Height540-BBUI
Broadcom 57412 Dual Port 10GbE SFP+ Adapter, PCIe Full Height540-BBUH
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height540-BBCT
Intel XXV710 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height540-BCDH
Mellanox ConnectX-5 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Full Height540-BCNM
Mellanox ConnectX-5 EX Dual Port 40 / 100GbE QSFP28 Adapter, PCIe Full Height540-BCIU
Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height540-BBUJ
Dual NIC ConfigurationNote: Dual 10G Base-T NICs, 1 x 540-BBUY + 1 x 540-BBRO Dual 10G SFP+ NICs, 1 x 555-BCKO + 1 x 540-BBHP Dual 25G NICs, 1 x 406-BBLG + 1 x 406- BBLE

R740xd 24 SFF Hardware Compatibility



ComponentDescriptionSKU
ChassisUse cases:Analytics and Big Data Database and Business Critical Apps Private Cloud Test and Development End-User Computing/Virtual Desktop Infrastructure Note:Only Legacy BIOS is supported. For chassis with GPU support, order the chassis SKU 321-BDHZ. For GPU support, order the power supply SKU 450-AGFO. For chassis with NVMe support, order the chassis SKU 321-BCRC.
PowerEdge R740xd ServerNodes per chassis: 1210-AKZR
Chassis with Up to 24 x 2.5" Hard Drives for 2CPUNodes per chassis: 1321-BCPY
Chassis with Up to 24 x 2.5 Hard Drives for 2CPU, GPU Capable ConfigurationNodes per chassis: 1321-BDHZ
Chassis up to 24 x 2.5 Hard Drives including 12 NVME Drives, 2CPU ConfigurationNodes per chassis: 1321-BCRC
boot drive1 x M.2 SSD
BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),FH403-BBPJ
BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),FH403-BBPT
BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),FH403-BCHP
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH403-BBSV
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH403-BCHJ
Power Supply2x Hot plug power supply
750W Dual, Hot-plug, Redundant Power Supply (1+1)450-ADWS
Dual, Hot-plug, Redundant Power Supply (1+1), 1100W450-ADWM
Dual, Hot-plug Power Supply, 2400W, 250 Volt Power Cord Required for Use450-AGFO
Dual, Hot-plug, Redundant Power Supply (1 + 1), 1600W, 250 Volt Power Cord Required for Use450-AFMQ
Embedded Systems ManagementiDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise385-BBKT
iDRAC PasswordiDRAC, Legacy Password379-BCSG
ComponentDescriptionSKU
Storage: All-FlashOnly SATA/SAS SSDs
8, 10, 12, 14, 16, 18, 20, 22, or 24 x 2.5" SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions.
480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ARXG (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASEO (EOS)
480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive400-BDSD (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW400-BCQG (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW400-AZHC (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW400-AZII (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASFO (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASFI
960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, S4600, 3 DWPD, 5256 TBW400-ASYL (EOS)
960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW400-BDSI
960GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 5256 TBW400-BCQN
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW400-BEPD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASGE (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive,400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883400-BCVC
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW400-BCOM
1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5400-BCMJ
1.92TB SATA RI SSD (1 DWPD), 512e, 6Gbps, 2.5", ISE, Samsung, PM883a, PE/PV345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW345-BBBP
Storage: All-FlashOnly SATA/SAS and NVMe SSDs
20 x 2.5" SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions.
480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ARXG (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASEO (EOS)
480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive400-BDSD (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW400-AZHC (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW400-AZII (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASFO (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASFI
960GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, S4600, 3 DWPD, 5256 TBW400-ASYL (EOS)
960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW400-BEPD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASGE (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive,400-BDSU
1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW400-BEQI
1.92TB SATA RI SSD (1 DWPD), 512e, 6Gbps, 2.5", ISE, Samsung, PM883a, PE/PV345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW345-BBBP
4 x NVMe SSDs
Dell 800GB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier400-AUMO (EOS)
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier400-AUMP (EOS)
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier400-BELT
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725b with Carrier400-BEFC
Dell 3.2TB NVMe Mix Use Express Flash 2.5in SFF Drive U.2 P4610400-BEDQ
Dell 6.4TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier400-BELR
Storage: HybridMix of SATA/SAS SSDs and HDDs
4, 6, or 8 x 2.5" SATA/SAS SSDsNote: The SSD SKUs 400-AYZI, 400-BDNK, 400-BDSI, 400-BDSU, and 400-BDSD are supported with Foundation 4.3.4 and higher versions.
480GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ARXG (EOS)
480GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASEO (EOS)
480GB SATA Mixed Use SSD 6Gbps 512e 2.5in Hot Plug S4610 Drive400-BDSD (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW400-BCQG (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW400-AZHC (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW400-AZII (EOS)
960GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASFO (EOS)
960GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV400-ASFI
960GB SATA SSD Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW400-BDSI
960GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 5256 TBW400-BCQN
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256TBW400-BEPD
1.92TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a400-ASGE (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV, 3 DWPD, 10512 TBW400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive,400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883400-BCVC
1.92TB SAS Mixed SSD use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW400-BCOM
1.92TB SAS Mixed Use SSD 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5400-BCMJ
1.92TB SATA RI SSD (1 DWPD), 512e, 6Gbps, 2.5", ISE, Samsung, PM883a, PE/PV345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a, 1 DWPD, 7008 TBW400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD, 7008 TBW400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW345-BBBP
8, 10, 12, 14, 16, 18, or 20 x 2.5" HDDsNote: The number of HDDs should be twice or more the number of SSDs.
1TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive400-ASH
1.2TB 10K RPM Self-Encrypting SAS 12Gbps 512n 2.5in Hot-plug Hard Drive, FIPS140400-ASHK
1.8TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive400-ARXC
2TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive400-ASHP
2.4TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive400-AVEZ
2.4TB 10K RPM Self-Encrypting SAS 12Gbps 512e 2.5in Hot-plug Hard Drive, FIPS140400-AVHH
Storage Controller1 x Storage Controller
HBA330 Controller Adapter, Low Profile405-AANK
HBA330 12Gbps SAS HBA Controller (NON-RAID), MiniCard405-AAJW
RAID OptionIn RAID780-BCDI
ComponentDescriptionSKU
CPU2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more colors per CPU).Various
MemoryDDR4-2666, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB370-ADND
DDR4-2666, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-ADNF
DDR4-2666, 1.2V, 64GB, LRDIMM12 x 64GB = 768GB 16 x 64GB = 1TB 24 x 64GB = 1.5TB Note: Select 2666MT/s LRDIMMs (SKU 370-ADNT) for memory DIMM type and speed option.370-ADNH
DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB Note:Select 2666MT/s LRDIMMs (SKU 370-ADNT) for memory DIMM type and speed option. For memory capacity higher than 768 GB and up to 1.5 TB per socket, order the Intel Skylake Xeon CPUs with suffix M.370-ADMX
ComponentDescriptionSKU
CPU2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more colors per CPU).Various
MemoryDDR4-3200, 1.2V, 8 GB, RDIMM12 x 8 GB = 96 GB 16 x 8 GB = 128 GB 24 x 8 GB = 192 GB370-AEVO
DDR4-2933, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB370-AQF
DDR4-3200, 1.2V, 16 GB, RDIMM12 x 16 GB = 192 GB 16 x 16 GB = 256 GB 24 x 16 GB = 384 GB370-AEVQ
DDR4-2933, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-AEQH
DDR4-3200, 1.2V, 32 GB, RDIMM12 x 32 GB = 384 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-EVN
DDR4-2933, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB370-AQD
DDR4-3200, 1.2V, 64 GB, RDIMM12 x 64 GB = 768 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB370-EVP
DDR4-2667, 1.2V, 128 GB, LRDIMM12 x 128 GB = 1.5 TB 16 x 128 GB = 2 TB 24 x 128 GB = 3 TB370-ADMX
ComponentDescriptionSKU
FlexibleLOM Adapter1 x Flexible LAN on Motherboard (FLOM) adapter
Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28, rNDC406-BBLG
Intel X550 Quad Port 10GbE BASE-T, rNDC540-BBUY
Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC540-BBUZ
Intel Ethernet I350 QP 1Gb Network Daughter Card540-BBDD
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC540-BBBB
Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC540-BBUK
Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC540-BOOM
Intel Ethernet I350 QP 1Gb Network Daughter Card540-BBB
Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC555-BCKO
PCIe Network Interface1x PCIe Network Interface
Mellanox ConnectX-4 LX Dual Port 10 / 25GbE SFP28 Adapter, PCIe Full Height406-BBLE
Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Full Height540-BBRO
Intel X710 Dual Port 10GbE Direct Attach SFP+ Adapter, PCIe Full Height540-BBHP
Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Low Profile, Customer Install540-BCCN
Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Full Height540-BBDH
Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Full Height540-BBUI
Broadcom 57412 Dual Port 10GbE SFP+ Adapter, PCIe Full Height540-BBUH
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height540-BBCT
Intel XXV710 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height540-BCDH
Mellanox ConnectX-5 Dual Port 10 / 25GbE SFP28 Adapter, PCIe Full Height540-BCNM
Mellanox ConnectX-5 EX Dual Port 40 / 100GbE QSFP28 Adapter, PCIe Full Height540-BCIU
Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height540-BBUJ
Dual NIC ConfigurationNote: Dual 10G Base-T NICs, 1 x 540-BBUY + 1 x 540-BBRO Dual 10G SFP+ NICs, 1 x 555-BCKO + 1 x 540-BBHP Dual 25G NICs, 1 x 406-BBLG + 1 x 406- BBLE
ComponentDescriptionSKU
GPU1 or 2 x GPUNote:For dual-GPU configuration, a combination of same GPUs is supported. Use the riser kit SKU 330-BBHH (Riser Config 4, 3 x 8, 4 x 16 slots, Double-Wide GPU compatible). Order a Heatsink and Install Kit for GPU Configuration; SKU 412-AAJK for M10 GPU and SKU 750-AAXX for P40 GPU. The GPU SKUs 490-BFRQ and 490-BFSG are supported with ESXi hypervisors. Starting from AOS 5.19, they are also supported with AHV.
NVIDIA Tesla M10 GPU, Requires GRID 2.0 SW for VDI Function489-BBCG
NVIDIA Tesla P40 24GB GPU (Single/Dual GPU)489-BBCN
Dell 16GB NVIDIA Tesla T4 GPU Graphic Card490-BEYM
NVIDIA® Tesla ™ V100 32GB, Passive, Double Wide, Full Height GPU490-BENY
NVIDIA Tesla V100S 32GB, 250W, Passive, Double Wide, Full Height GPU490-BFRR
NVIDIA® Tesla ™ V100 16GB, Passive, Double Wide, Full Height GPU490-BEDZ
NVIDIA Quadro RTX 6000 24GB, 250W, Dual Slot, PCIe x16 Passive Cooled, Full Height GPU490-BFRQ
NVIDIA Quadro RTX 8000 48 GB, 250W, Dual Slot, PCIe x16 Passive Cooled, Full Height GPU490-BFSG

R630 10 SFF Hardware Compatibility



ComponentDescriptionSKU
ChassisUse cases:Analytics and Big Data Remote Office/Branch Office End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported.
PowerEdge R630 ServerNodes per chassis: 1210-ACXS
1 RU Chassis with up to 10, 2.5" Hard Drives, 3 PCIe SlotsNodes per chassis: 1321-BBKM
boot drive1 x 64 GB Solid State SATA-DOM Boot DriveNote: The following hypervisors are supported: VMware ESXi 6.0u2 and Nutanix AHV400-AOQL
Power Supply2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1 + 1), 1100W450-ADWM
Embedded Systems ManagementiDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise385-BBHO
ComponentDescriptionSKU
Storage: HybridMix of SATA SSDs and HDDs
2 x 2.5" SATA SSDs
480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMID
800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIFQ
960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHE
1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIGF
1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHH
4, 6, or 8 x 2.5" HDDs
1TB 7.2K RPM Near-Line SAS 2.5in Hot-plug Hard Drive400-STUDENT
2TB 7.2K RPM NLSAS 512n 2.5in Hot-plug Hard Drive400-AMUC
Storage: All-FlashOnly SATA/SAS SSDs
2 or 10 x 2.5" SATA/SAS SSDs
480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMID
800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIFQ
960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHE
1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIGF
1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHH
3.84TB Solid State Drive Serial Attached SCSI (SAS) Read Intensive 12Gbps 512e 2.5in Hot-plug Drive - PM1633a400-AQNT
RAID OptionNo RAID for HBA330/H330/H730/H730P (Inc Flex Bay) w/ SATADOMNote: This description does not indicate the list of supported controllers. Nutanix supports only HBA330 12Gbps SAS HBA Controller in R630 10 SFF.780-BCCZ
Storage Controller1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard405-YYYY
ComponentDescriptionSKU
CPU2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higherNote: The specified processor is the lowest supported processor. Higher processors are also supported.Various
MemoryDDR4-2400, 1.2V, 16GB, RDIMM8 x 16GB = 128GB 16 x 16GB = 256GB370-ACNX
DDR4-2400, 1.2V, 32 GB, RDIMM8 x 32 GB = 256 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-ACNS
DDR4-2400, 1.2V, 64 GB, LRDIMM8 x 64 GB = 512 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Use the memory options 370-AAIP (Memory Configuration Type: Performance Optimized) and 370 -ACPG (Memory DIMM Type and Speed: 2400MT/s LRDIMMs) for selecting the 64 GB DIMM in Dell Configurator.370-ACNV
ComponentDescriptionSKU
Network Interface1 x Network Interface
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC540-BBBB
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height540-BBCT
Dual NIC ConfigurationNote: Dual 10G NICs, 1 x 540-BBBB + 1 x 540-BBCT

R730xd 12 LFF Hardware Compatibility



ComponentDescriptionSKU
ChassisUse cases:Analytics and Big Data Backup and Disaster Recovery Files and Objects Private Cloud Test and Development End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported.
PowerEdge R730xd ServerNodes per chassis: 1210-ADBC
2 RU Chassis with up to 12, 3.5" Hard DrivesNodes per chassis: 1350-BEU
boot drive1 x 64 GB Solid State SATA-DOM Boot DriveNote: The following hypervisors are supported: VMware ESXi 6.0u2 and Nutanix AHV400-AOQL
Power Supply2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1 + 1), 1100W450-ADWM
Embedded Systems ManagementiDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise385-BBHO
ComponentDescriptionSKU
Storage: HybridMix of SATA SSDs and HDDs
2 or 4 x 3.5" SATA SSDs
480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863400-AMHB
800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610400-AGG
960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863400-FRIEND
1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610400-AIFO
1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive 3.5in HYB CARR, SM863400-AMIX
8 or 10 x 3.5" HDDs
2TB 7.2K RPM NLSAS 512n 3.5in Hot-plug Hybrid Carrier Hard Drive400-ALPB
4TB 7.2K RPM NLSAS 512n 3.5in Hot-plug Hybrid Carrier Hard Drive400-ALOV
4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive400-ALNY
8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard DriveNote: AOS 5.11 and above supports a maximum of 120TB storage per node.400-AMPP
8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Drive400-AMPG
Storage: All-FlashOnly SATA SSDs
12 x 3.5" SATA SSDs
480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863400-AMHB
800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610400-AGG
960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863400-FRIEND
1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610400-AIFO
1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive 3.5in HYB CARR, SM863400-AMIX
RAID OptionNo RAID for HBA330/H330/H730/H730P (Inc Flex Bay) w/ SATADOMNote: This description does not indicate the list of supported controllers. Nutanix supports only HBA330 12Gbps SAS HBA Controller in R730xd 12 LFF.780-BCCT
Storage Controller1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard405-YYYY
ComponentDescriptionSKU
CPU2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher.Note: The specified processor is the lowest supported processor. Higher processors are also supported.Various
MemoryDDR4-2400, 1.2V, 16GB, RDIMM8 x 16GB = 128GB 16 x 16GB = 256GB370-ACNX
DDR4-2400, 1.2V, 32 GB, RDIMM8 x 32 GB = 256 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-ACNS
DDR4-2400, 1.2V, 64 GB, LRDIMM8 x 64 GB = 512 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Use the memory options 370-AAIP (Memory Configuration Type: Performance Optimized) and 370 -ACPG (Memory DIMM Type and Speed: 2400MT/s LRDIMMs) for selecting the 64 GB DIMM in Dell Configurator.370-ACNV
ComponentDescriptionSKU
Network Interface1 x Network Interface
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC540-BBBB
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height540-BBCT
Dual NIC ConfigurationNote: Dual 10G NICs, 1 x 540-BBBB + 1 x 540-BBCT

R730xd 24 SFF Hardware Compatibility



ComponentDescriptionSKU
ChassisUse cases:Analytics and Big Data Database and Business Critical Apps Private Cloud Test and Development End-User Computing/Virtual Desktop Infrastructure Note: Only Legacy BIOS is supported.
PowerEdge R730xd ServerNodes per chassis: 1210-ADBC
2 RU Chassis with up to 24, 2.5" Hard DrivesNodes per chassis: 1350-BBFD
boot drive1 x 64 GB Solid State SATA-DOM Boot DriveNote: The following hypervisors are supported: VMware ESXi 6.0u2 and Nutanix AHV400-AOQL
Power Supply2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1 + 1), 1100W450-ADWM
Embedded Systems ManagementiDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise385-BBHO
ComponentDescriptionSKU
Storage: HybridMix of SATA/SAS SSDs and HDDs
4 x 2.5" SATA/SAS SSDs
480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMID
800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIFQ
960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHE
1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIGF
1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHH
3.84TB Solid State Drive SAS RI 12Gbps 512e 2.5in Hot-plug Drive, PM1633a400-AQNF
20 x 2.5" HDDs
1TB 7.2K RPM Near-Line SAS 2.5in Hot-plug Hard Drive400-STUDENT
2TB 7.2K RPM NLSAS 512n 2.5in Hot-plug Hard Drive400-AMUC
Storage: All-FlashOnly SATA/SAS SSDs
24 x 2.5" SATA/SAS SSDs
480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMID
800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIFQ
960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHE
1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIGF
1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHH
3.84TB Solid State Drive SAS RI 12Gbps 512e 2.5in Hot-plug Drive, PM1633a400-AQNF
RAID OptionNo RAID for HBA330/H330/H730/H730P (Inc Flex Bay) w/ SATADOMNote: This description does not indicate the list of supported controllers. Nutanix supports only HBA330 12Gbps SAS HBA Controller in R730xd 24 SFF.780-BCCT
Storage Controller1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard405-YYYY
ComponentDescriptionSKU
CPU2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher.Note: The specified processor is the lowest supported processor. Higher processors are also supported.Various
MemoryDDR4-2400, 1.2V, 16GB, RDIMM8 x 16GB = 128GB 16 x 16GB = 256GB370-ACNX
DDR4-2400, 1.2V, 32 GB, RDIMM8 x 32 GB = 256 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-ACNS
DDR4-2400, 1.2V, 64 GB, LRDIMM8 x 64 GB = 512 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Use the memory options 370-AAIP (Memory Configuration Type: Performance Optimized) and 370 -ACPG (Memory DIMM Type and Speed: 2400MT/s LRDIMMs) for selecting the 64 GB DIMM in Dell Configurator.370-ACNV
ComponentDescriptionSKU
Network Interface1 x Network Interface
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC540-BBBB
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height540-BBCT
Dual NIC ConfigurationNote: Dual 10G NICs, 1 x 540-BBBB + 1 x 540-BBCT

R730 16 SFF Hardware Compatibility



ComponentDescriptionSKU
ChassisUse cases:Analytics and Big Data Database and Business Critical Apps Note: Only Legacy BIOS is supported.
PowerEdge R730 ServerNodes per chassis: 1210-ACXU
2 RU Chassis with up to 16, 2.5" Hard DrivesNodes per chassis: 1350-BBIL
boot drive1 x 64 GB Solid State SATA-DOM Boot DriveNote: The following hypervisors are supported: VMware ESXi 6.0u2 and Nutanix AHV400-AOQL
Power Supply2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1 + 1), 1100W450-ADWM
Embedded Systems ManagementiDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise385-BBHO
ComponentDescriptionSKU
Storage: HybridMix of SATA SSDs and HDDs
2 or 4 x 2.5" SATA SSDs
480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMID
800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIFQ
960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHE
1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIGF
1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHH
4, 6, 8, 12, or 14 x 2.5" HDDsNote: The HDDs need to be twice or more the number of SSDs.
1TB 7.2K RPM Near-Line SAS 2.5in Hot-plug Hard Drive400-STUDENT
2TB 7.2K RPM NLSAS 512n 2.5in Hot-plug Hard Drive400-AMUC
Storage: All-FlashOnly SATA SSDs
16 x 2.5" SATA SSDs
480GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMID
800GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIFQ
960GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHE
1.6TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610400-AIGF
1.92TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863400-AMHH
RAID OptionNo RAID for HBA330 (1-16 HDDs or SSDs) SATADOM780-BCCS
Storage Controller1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard405-YYYY
ComponentDescriptionSKU
CPU2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher.Note: The specified processor is the lowest supported processor. Higher processors are also supported.Various
MemoryDDR4-2400, 1.2V, 16GB, RDIMM8 x 16GB = 128GB 16 x 16GB = 256GB370-ACNX
DDR4-2400, 1.2V, 32 GB, RDIMM8 x 32 GB = 256 GB 16 x 32 GB = 512 GB 24 x 32 GB = 768 GB370-ACNS
DDR4-2400, 1.2V, 64 GB, LRDIMM8 x 64 GB = 512 GB 16 x 64 GB = 1 TB 24 x 64 GB = 1.5 TB Note: Use the memory options 370-AAIP (Memory Configuration Type: Performance Optimized) and 370 -ACPG (Memory DIMM Type and Speed: 2400MT/s LRDIMMs) for selecting the 64 GB DIMM in Dell Configurator.370-ACNV
ComponentDescriptionSKU
Network Interface1 x Network Interface
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC540-BBBB
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height540-BBCT
Dual NIC ConfigurationNote: Dual 10G NICs, 1 x 540-BBBB + 1 x 540-BBCT

Some segments we help



Third-party maintenance for Nutanix End-of-Life (EOL) and Nutanix End-of-Service-Life (EOSL)



A DC Parts made an analysis on more than 250 customer contracts that use storage, servers, networks and tapes and showed us that 40-60% of the equipment of these customers operate beyond the end dates of support.

There are simple options for you to reduce your expenses and feel more confident about your IT infrastructure. When you choose a custom solution to extend the life of your IT equipment, you can make big savings.



How can we help:



We offer our customers a unique assessment to help analyze their OEM support contracts and understand exactly which devices can be supported in the most affordable way, without compromising their performance.



Nutanix hardware support



Support services DC Parts provide support for Nutanix hardware. We work to match the right approach with the right equipment to meet your Nutanix hardware support needs.

With a highly trained team of certified engineers ready to troubleshoot any Nutanix hardware issues, DC Parts is uniquely qualified to serve you. If you would like to speak with a representative about purchasing support on Nutanix hardware, contact us.

A DC Parts helps companies of all sizes better manage their IT data centers by providing third-party support services to leading equipment manufacturers, including: Dell, IBMHPEnetapp, Oracle SunCisco and more.

With support DC Parts, we manage all your hardware, between the manufacturers through a link. Support from DC Parts offers flexible service level agreements, certified engineering support teams and dedicated customer service representatives.

Extend the life and value of your IT assets. Contact DC Parts Support immediately.

Request a quote with us and answer any questions you may have.






    Contact DC Parts and we will help you better optimize your IT investment

    Questions?

    Call our product team at + 011 3022 4694-XNUMX or send an email to: contato@dcparts.com.br

    Warranty:

    All the hardware in the DC Parts is fully tested, guaranteed and comes with a 90-day warranty. Above all, we will support you before, during and after the sale.



    Product Experience:

    In other words, we know how important it is that you get the product you need to meet your needs. In addition, we have a sales team and agile logistics to make the shortest possible delivery times possible.

    Sending proposals within 2 business days, experimenting with data centers and integrators and we always try to get the best price.

    Do not hesitate to contact us with any questions about compatibility, condition or the best product available for your need.

    Our website represents only a fraction of the pieces we work with. But you can contact your complete requirements or equipment lists.

    Select currency
    PENSalt
