DELL server support and maintenance



The Dell PowerEdge servers you have in your IT infrastructure can still provide the functionality, flexibility and practicality for the vast majority of organizations today. The ability to add additional memory (if not already specified at time of purchase) and CPU provides customers with a variety of options to upgrade their host servers (virtualized environments) to continue to deliver the required performance beyond the manufacturers' end-of-life dates. These potential upgrade options mean that customers do not have to constantly look for new server solutions at the end of a 3 or 5 year internal lifecycle program because the servers are no longer fit for purpose.

Third party maintenance of the DELL server



DC Parts provides organizations with a viable and sustainable alternative option to extend the life of their Dell servers after the 'end of life' or 'end of life support' announcements, while being able to provide recommended hardware upgrade options , which includes and incorporates the complete installation and configuration work performed by experienced technical field engineers. Our ability to continue to provide an alternative server maintenance support service for Dell PowerEdge servers further supports organizations by offering a cost-effective solution for mission-critical Dell PowerEdge servers. This solution significantly reduces your total cost of ownership and also generates a greater return on your initial capital expenditures with IT server hardware.

DC Parts offers a flexible approach for organizations looking to partially or fully integrate maintenance and support services into their organization for current or historical server systems. These service levels range from NBD (Next Business Day) to a 24/7 response. Our maintenance and support services range from parts only to telephone and remote support. Our service level pages describe these and other services in detail.

Sign in contact with us to see if we can provide the guarantees you need, especially to explore an alternative maintenance support service.

Residual asset value for your DELL hardware



Our exclusive DELL server maintenance and support service can provide you with the potential to customize a cost-neutral maintenance contract for the DELL server that is now post-warranty, end of life or end of life (EOL / EOSL) . Our service allows customers with DELL hardware to have multiple stages in a lifecycle program, while providing extended maintenance support, regardless of the need for 3,6,9 or even 12 months of support, thereby effectively creating a solution cost-neutral.



Cost reduction in your contract



We allow a cost-neutral maintenance solution to be provided through the residual value on your DELL server hardware that we would remove at the end of the agreed maintenance support term. As well as services for secure deactivation and elimination of data according to internal compliance requirements will also be part of the discussion of the hardware lifecycle services program.

If you don't need a support service, our maintenance service can still benefit you. So we can provide a residual value quote for your IT server and storage hardware and discuss the process of deactivating and deleting data, allowing you to get a much higher return on your initial capital investment. There is no obligation to obtain a quote from DC Parts, but it does allow you to explore whether this service can be viable and beneficial for you.

Find out more by going to contact us.

Dell grew from a humble beginning as  PC Limited selling IBM PC-compatible computers directly to end users. This ethos of selling directly to customers remains today, however, now no data center is without a significant amount of Dell Poweredge equipment installed. Partnering with companies and buying others, Dell developed a portfolio with the goal of making them a 'one stop shop' for IT infrastructure. PowerEdge servers have a solid reputation for being reliable and economical. Its PERC (PowerEdge RAID Controllers) use industry-leading architecture from companies like LSI, while using custom features like background patrol reading to fix bad sectors on online RAID disks. With models ranging from 1U rackmount models, tower variants for the SMB market and high-density blade systems, Dell PowerEdge servers have gained a large share in the modern IT market.

DC Parts has extensive knowledge of Dell PowerEdge hardware and our team has years of experience with PowerEdge systems. DC Parts can customize a support package to meet your organization's immediate or long-term needs, from short-term 9 to 5 contracts to annual maintenance packages 24 hours a day, 7 days a week. DC Parts consultants work with customers to ensure they get the guarantees they need at a cost that suits their budget. Our flexibility, together with our comprehensive understanding of the PowerEdge line, allows DC Parts to help organizations maximize investment in their IT infrastructure.



Benefits of maintenance support DC Parts in storage Dell PowerEdge

  • Technical diagnostics and repair of Dell PowerEdge servers
  • Level 3 engineer assigned to an account
  • Global service availability
  • Maintenance support for current and end-of-life Dell equipment
  • Pro-rata support and co-termination dates
  • Site audits / surveys
  • Data / platform migration
  • IT decommissioning
  • Data erasure
  • Highly experienced and specially trained technical field engineers
  • On-site spare parts cache
  • Various methods for generating a fault ticket ticket
  • Helpdesk assistance
  • Operating system and firmware recommendations
  • Professional services
    • Consulting
    • VMware
    • Hardware upgrades
  • Flexible short and long-term maintenance support contracts
  • Hardware rental
  • DMR (digital media retention)
  • Operational savings



End of support Dell PowerEdge, but not DC Parts

Dell EMC PowerEdge One Socket Rack Servers Technical Specifications

The single-socket Dell EMC PowerEdge server is designed to handle workloads such as virtualization, HCI, and OpenStack Ready Architecture. Boost performance, scalability and simplify IT with the One Socket server designed for companies with remote and branch offices.



Model

Processor

Memory

Controllers

Drive Bays

I / O & Ports

Slots

PowerEdge R220

Intel® Xeon® processor E3-1200 v3 product family, Intel Pentium®, Intel Celeron®, Intel Core®

4 x DDR3 UDIMM, up to 32GB, up to 1600MT/s

Internal controllers: • PERC S110 (SW RAID) • PERC H310 • Chipset-based SATA External HBAs (RAID): • PERC H810 External HBAs (non-RAID): • 6Gbps SAS HBA

Drive bay options: • Up to 2 x 2.5” • Up to 2 x 3.5” • 1 slim optical drive Hard drive options: • 2 x 3.5” SATA, SAS, or NL SAS • 2 x 2.5” SAS, NL SAS or SSD

1Gb/10Gb Ethernet 10Gb Converged Ethernet



PowerEdge R230

1 processor from the following product families: • Intel® Xeon® processor E3-1200 v6 product family • Intel Pentium® • Intel CoreTM i3 • Intel Celeron®

Architecture: Up to 2400MT/s DDR4 DIMMs Memory type: UDIMMs Memory module sockets: 4 Maximum RAM: Up to 64GB

• 2.5″ SATA 7.2k • 2.5″ nearline SAS 7.2k • 2.5″ 10k SAS HDDs • 2.5″ 15K SAS HDDs • 2.5″ SATA SSDs
• 3.5″ Enterprise SATA 7.2k HDDs
• 3.5″ nearline SAS 7.2k HDDs
• 3.5″ 7.2k SATA entry drives

2 x 3.5″ cabled HDD 4 x 3.5″ cabled HDD 4 x 3.5″ hot-swap or 2.5″ hot-swap in hybrid drive carrier



2 x PCIe 3.0 slots: x16 slot, full-height (1×8 3.0)+ x8 slot, low-profile (1×4 3.0)

PowerEdge R240

1 processor from the following: Intel® Xeon® E-2100 product family, Intel Pentium®, Intel Core i3®, Intel Celeron®

4 x DDR4 DIMM slots, Supports UDIMM, up to 2666MT/s, 64GB Max. Supports registered ECC

Internal controllers: PERC H730P, H330, HBA330 (non-RAID) Software RAID: PERC S140 External HBAs: 12Gbps SAS HBA (non-RAID) Boot Optimized Storage Subsystem: 2x M.2 240GB (RAID 1 or No RAID), 1x M .2 240GB (No RAID only)

Up to 4 x 3.5 wired SATA, SAS (optional) or SSD* Up to 4 x 3.5 or 2.5 hot-plug SATA, SAS (optional) or SSD* *available in the hot-plug configuration

Networking Options: 2 x 1GbE LOM Network Interface Controller (NIC) ports Front ports: 1 x USB 2.0, 1 x IDRAC micro USB 2.0 management port Rear ports: 2 x USB 3.0, VGA, serial connector
1x USB 2.0, 1x IDRAC micro USB 2.0 management port



PowerEdge R320

Intel® Xeon® processor E5-2400 product family Intel Xeon processor E5-1410 Intel Pentium® processor 1400 product family

Up to 96GB (6 DIMM slots): 2GB/4GB/8GB/16GB DDR3 up to 1600MHz

Internal controllers: PERC S110 (RAID SW) PERC H310 PERC H710 External HBAs (RAID): PERC H810 External HBAs (non-RAID): 6Gbps SAS HBA

Up to eight 2.5” hot-plug SAS, SATA or SSD or four 3.5” SAS, SATA



2 PCIe slots: • One x8 PCIe slot with x4 bandwidth, half-length, half-height • One x16 PCIe slot with x16 bandwidth, half-length, full-height

PowerEdge R330

1 processor from the following product families: • Intel® Xeon® processor E3-1200 v6 product family • Intel Pentium® • Intel CoreTM i3 • Intel Celeron®

Architecture: Up to 2400MT/s DDR4 DIMMs Memory type: UDIMMs Memory module sockets: 4 Maximum RAM: Up to 64GB

• 1.8″ SSDs • 2.5″ SATA SSDs • 2.5″ SATA 7.2k • 2.5″ SAS 15k HDDs • 2.5″ nearline SAS 7.2k
• 2.5″ SAS 10K HDDs
• 3.5″ Enterprise SATA 7.2k HDDs
• 3.5″ nearline SAS 7.2k HDDs

• Up to 4 x 3.5″ cabled HDD plus optional 2 x 1.8″ SSD cabled • Up to 4 x 3.5″ hot-swap HDD • Up to 8 x 2.5″ hot-swap HDD • UP to 4 x 2.5″ hot-swap HDD (available via hybrid drive carrier)



2 x PCIe 3.0 slots + 1 slot for internal storage

PowerEdge R340

1 processor from the following: Intel® Xeon® E-2100 product family, Intel Pentium® , Intel Core i3® , Intel Celeron®

4 x DDR4 DIMM slots, Supports UDIMM, up to 2666MT/s, 64GB Max. Supports registered ECC

Internal controllers: PERC H730P, H330, HBA330 (non-RAID) Software RAID: PERC S140 External HBAs: 12Gbps SAS HBA (non-RAID) Boot Optimized Storage Subsystem: 2x M.2 240GB (RAID 1 or No RAID), 1x M .2 240GB (No RAID only)

Up to 8 x 2.5 hot-plug SATA, SAS (optional) or SSD Up to 4 x 3.5 hot-plug SATA, SAS (optional) or SSD

Networking Options: 2 x 1GbE LOM Network Interface Controller (NIC) ports Front ports: 1 x USB 2.0, 1 x IDRAC micro USB 2.0 management port Rear ports: 2 x USB 3.0, VGA, serial connector 2 x PCIe Gen 3.0 slots:
• One x8 low-profile slot, half-length with x4 slot width
• One x16 slot low-profile/full-height, half-length
with x8 bandwith



PowerEdge R6415

1x AMD EPYC™ processor, up to 32 colors

16 DDR4 DIMM slots, Supports RDIMM, LRDIMM



Front drive bays: Up to 8 x 2.5” SAS/SATA/NVMe + 2 x 2.5 NVMe or up to 4 x 3.5” SAS/SATA HDD

Network daughter card options: Optional LOM: 2 x 1GE or 2 x 10GE or 2 x 10GE SFP+ Front ports: Video, 1 x USB 2.0, dedicated iDRAC Direct USB Rear Ports: Video, Serial, 2 x USB 3.0, dedicated iDRAC network port Riser options with up to 2 x Gen3 slots; 2 x 16 lanes



PowerEdge R7415

1x AMD™ EPYC processor, up to 32 colors

16 DDR4 DIMMs, RDIMM, LRDIMM

Internal Controllers: PERC H330, H730p, H740p, HBA330 Boot Optimized Storage System: HW RAID 2 x M.2 + Internal USB + Internal Dual SD Module External PERC (RAID): H840 12Gbps PERC9 or 10 series, mini PERC x8 slot

Front Drive Bays: Up to 24 x 2.5” SATA/SAS/NVMe or up to 12x 3.5” SAS/SATA HDD Rear Drive Bays: Up to 2×3.5” SAS/SATA HDD

Network daughter card options: Optional LOM: 2 x 1GE or 2 x 10GE or 2 x 10GE SFP+ Front ports: Video, 2 x USB 2.0, dedicated iDRAC Direct Micro-USB Rear Ports: LOM: 2 x 1GE, Video, Serial, 2 x USB 3.0, dedicated iDRAC Riser Options with up to 4 x Gen3 slots; 3 x 16 lanes and 1 x 8 lanes



Dell EMC PowerEdge Two-Socket Rack Servers Technical Specifications

Address key applications with the latest product families of Intel® Xeon® processors E5-2400 and E5-2400 v2 – designed to be a foundation for flexible and efficient data centers that can easily scale to meet growing needs. The high-density design of two-socket configurations with up to 12 dual inline memory modules (DIMMs) to support consolidated and virtualized environments.



Model Processor Memory Controllers Drive Bays I / O & Ports
PowerEdge R820 Intel® Xeon® processor E5-4600 product family Up to 1.5TB
(48 DIMM slots):
2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MHz
Internal controllers:
PERC H310
PERC H710
PERC H710P
External HBAs (RAID):
PERC H810
External HBAs (non-RAID):
6Gbps SAS HBA
Up to sixteen 2.5” hot-plug SAS, SATA, or SSD 7 PCIe slots:
Two x16
One x8
three x8
One x8
All options half-length, full-height
PowerEdge R830 Intel® Xeon® processor E5-4600 v4 product family (48 DIMM slots): 8GB/16GB/32GB/64GB DDR4, RDIMM, LRDIMM up 2400MT/s Internal controllers: PERC H330, PERC H730, PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA Up to 16 x 2.5″ 7 PCIe slots: • 2x16 half-length, full-height • 1x8 half-length, full-height • 3x8 half-length, half-height • 1x8 half-length, full-height for the RAID controller
PowerEdge R840 Up to four Intel® Xeon® Scalable processors, up to 28 colors each 48 DDR4 DIMM slots, Supports RDIMM /LRDIMM, up to 2666MT/s, 6TB max Up to 12 NVDIMMs, 384GB Max Supports registered ECC DDR4 DIMMs only Internal Controllers: PERC H730P, H740P, H330 Software RAID (SWRAID) S140 Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB or 240GB External PERC (RAID): H840 12Gbps SAS HBAs (non-RAID): External-12Gbps SAS HBA (non-RAID), Internal- HBA330 (non-RAID) Front drive bays: Up to 8x 2.5” SAS SATA (HDDs/SSDs) max 30TB, or up to 24 x 2.5” SAS/SATA (HDDs/SSDs) with up to 12 NVMe PCIe SSDs max 122TB, or up to 24 NVMe PCIe SSDs max 153TB Rear drive bays: Up to 2 x 2.5” SAS/SATA (HDDs/SSDs), max 7.68TB Network Daughter Card Options 4 x 1GE, 4 x 10GE, 2 x 10GE+2 x 1GE, or 2 x 25GE Front ports: Video, 2 x USB 2.0, 1 dedicated IDRAC Direct Micro-USB. (Optional 1 x USB 3.0 only offered on the 8-drive configuration). Rear ports: Video, serial, 2 x USB 3.0
Internal port: 1 x USB 3.0
Video card: VGA
PCIe: Up to 6 x Gen3 slots, (4×16 slots or 2×16 + 4×8 slots)
PowerEdge R920 Intel Xeon processor E7‐4800 v2 and  E7‐8800 v2 product families (up to  4); Intel Xeon processor E7‐2800 v2  product family (up to 2) 96 DIMM slots, up to 6TB Internal controllers: PERC H730P External HBAs (RAID): PERC H810 6Gbps SAS HBA Up to 24 2.5” hot‐plug 12Gb/6Gb SAS HDD or SAS/SATA SSD Up to 8 front‐accessible Express Flash NVMe PCIe SSD (PCIe 3.0) Up to 10 PCIe slots; 8 PCIe 3.0, + 1 RAID slot, + 1 NDC slot + 2 optional PCIe slots
PowerEdge R930 Intel Xeon E7-8800 v4 and E7-4800 v4 processors Up to 12TB (96 DIMM slots): 8GB/16GB/32GB/64GB/128GB DDR4, RDIMM, LRDIMM up 2400MT/s Internal controllers: PERC H330, PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA Up to 24 2.5″ hot-plug 12Gb/6Gb SAS HDD or SAS/SATA SSD Up to 8 front-accessible Express Flash NVMe PCIe SSD (PCIe 3.0) Up to 10 PCIe 3.0 slots + 1 RAID slot + 1 NDC slot
PowerEdge R940 Up to four Intel® Xeon® SP, up to 28 colors 48 DDR4 DIMM slots, Supports RDIMM /LRDIMM, up to 2666MT/s, 6TB max Up to 12 NVDIMM, 192 GB Max Supports registered ECC DDR4 DIMMs only Internal controllers: PERC S140, H330, H740P Boot optimized Storage Subsystem External HBAs (RAID): H840 External HBAs (non-RAID): 12 Gbps SAS HBA Front drive bays: Up to 24 x 2.5” SAS/SATA (HDD/SSD) with up to 12 NVMe PCIe SSD, max 122TB Network daughter card options 4x 1Gb, 4x 10Gb, 2x 10Gb+2x 1Gb, or 2x 25Gb Front ports: Video, 2x USB 3.0, dedicated IDRAC Direct USB Rear ports: Video, serial, 2x USB 3.0, dedicated iDRAC network port Video card: VGA Up to 13 x Gen3 slots, (3 x8 + 10 x16)
PowerEdge R940xa Up to four Intel® Xeon® Scalable processors, up to 28 colors each 48 DDR4 DIMM slots, Supports RDIMM /LRDIMM, up to 2666MT/s, 6TB max Up to 12 NVDIMMs, 384GB Max Supports registered ECC DDR4 DIMMs only Internal Controllers: PERC H730P, H740P, H330 Software RAID (SWRAID) S140 Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB or 240GB External PERC (RAID): H840 12Gbps SAS HBAs (non-RAID): External-12Gbps SAS HBA (non-RAID). Internal- HBA330 (non-RAID) Front drive bays: Up to 8x 2.5” SAS SATA (HDD/SSD) max 30TB, or up 24 x 2.5” SAS/SATA (HDD/SSD) max 92TB, or up to 32 SAS/SATA (HDD/SSD) with up to 4 NVME PCIe SSD max 132TB Network Daughter Card Options 4 x 1GE, 4 x 10GE, 2 x 10GE+2 x 1GE, or 2 x 25GE Front ports: Video, 2 x USB 2.0, 1 dedicated IDRAC Direct Micro-USB. (Optional 1 x USB 3.0 only offered on the 8-drive configuration). Rear ports: Video, serial, 2 x USB 3.0
Internal port: 1 x USB 3.0
Video card: VGA
PCIe: Up to 12 x Gen3 slots, (6×16 slots or 2×16 + 10×8 slots)

Dell EMC PowerEdge Rack Four Socket Servers Technical Specifications

Leverage your mission-critical applications and make real-time decisions with 4-socket PowerEdge servers. Accelerate the GPU database for business-critical applications with a powerful four-socket server. Scale capacity with large internal storage. Up to four scalable 2nd generation Intel® Xeon® processors with up to 28 cores per processor.



Model Processor Memory Controllers Drive Bays I / O & Ports
PowerEdge R820 Intel® Xeon® processor E5-4600 product family Up to 1.5TB
(48 DIMM slots):
2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MHz
Internal controllers:
PERC H310
PERC H710
PERC H710P
External HBAs (RAID):
PERC H810
External HBAs (non-RAID):
6Gbps SAS HBA
Up to sixteen 2.5” hot-plug SAS, SATA, or SSD 7 PCIe slots:
Two x16
One x8
three x8
One x8
All options half-length, full-height
PowerEdge R830 Intel® Xeon® processor E5-4600 v4 product family (48 DIMM slots): 8GB/16GB/32GB/64GB DDR4, RDIMM, LRDIMM up 2400MT/s Internal controllers: PERC H330, PERC H730, PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA Up to 16 x 2.5″ 7 PCIe slots: • 2x16 half-length, full-height • 1x8 half-length, full-height • 3x8 half-length, half-height • 1x8 half-length, full-height for the RAID controller
PowerEdge R840 Up to four Intel® Xeon® Scalable processors, up to 28 colors each 48 DDR4 DIMM slots, Supports RDIMM /LRDIMM, up to 2666MT/s, 6TB max Up to 12 NVDIMMs, 384GB Max Supports registered ECC DDR4 DIMMs only Internal Controllers: PERC H730P, H740P, H330 Software RAID (SWRAID) S140 Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB or 240GB External PERC (RAID): H840 12Gbps SAS HBAs (non-RAID): External-12Gbps SAS HBA (non-RAID), Internal- HBA330 (non-RAID) Front drive bays: Up to 8x 2.5” SAS SATA (HDDs/SSDs) max 30TB, or up to 24 x 2.5” SAS/SATA (HDDs/SSDs) with up to 12 NVMe PCIe SSDs max 122TB, or up to 24 NVMe PCIe SSDs max 153TB Rear drive bays: Up to 2 x 2.5” SAS/SATA (HDDs/SSDs), max 7.68TB Network Daughter Card Options 4 x 1GE, 4 x 10GE, 2 x 10GE+2 x 1GE, or 2 x 25GE Front ports: Video, 2 x USB 2.0, 1 dedicated IDRAC Direct Micro-USB. (Optional 1 x USB 3.0 only offered on the 8-drive configuration). Rear ports: Video, serial, 2 x USB 3.0
Internal port: 1 x USB 3.0
Video card: VGA
PCIe: Up to 6 x Gen3 slots, (4×16 slots or 2×16 + 4×8 slots)
PowerEdge R920 Intel Xeon processor E7‐4800 v2 and  E7‐8800 v2 product families (up to  4); Intel Xeon processor E7‐2800 v2  product family (up to 2) 96 DIMM slots, up to 6TB Internal controllers: PERC H730P External HBAs (RAID): PERC H810 6Gbps SAS HBA Up to 24 2.5” hot‐plug 12Gb/6Gb SAS HDD or SAS/SATA SSD Up to 8 front‐accessible Express Flash NVMe PCIe SSD (PCIe 3.0) Up to 10 PCIe slots; 8 PCIe 3.0, + 1 RAID slot, + 1 NDC slot + 2 optional PCIe slots
PowerEdge R930 Intel Xeon E7-8800 v4 and E7-4800 v4 processors Up to 12TB (96 DIMM slots): 8GB/16GB/32GB/64GB/128GB DDR4, RDIMM, LRDIMM up 2400MT/s Internal controllers: PERC H330, PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA Up to 24 2.5″ hot-plug 12Gb/6Gb SAS HDD or SAS/SATA SSD Up to 8 front-accessible Express Flash NVMe PCIe SSD (PCIe 3.0) Up to 10 PCIe 3.0 slots + 1 RAID slot + 1 NDC slot
PowerEdge R940 Up to four Intel® Xeon® SP, up to 28 colors 48 DDR4 DIMM slots, Supports RDIMM /LRDIMM, up to 2666MT/s, 6TB max Up to 12 NVDIMM, 192 GB Max Supports registered ECC DDR4 DIMMs only Internal controllers: PERC S140, H330, H740P Boot optimized Storage Subsystem External HBAs (RAID): H840 External HBAs (non-RAID): 12 Gbps SAS HBA Front drive bays: Up to 24 x 2.5” SAS/SATA (HDD/SSD) with up to 12 NVMe PCIe SSD, max 122TB Network daughter card options 4x 1Gb, 4x 10Gb, 2x 10Gb+2x 1Gb, or 2x 25Gb Front ports: Video, 2x USB 3.0, dedicated IDRAC Direct USB Rear ports: Video, serial, 2x USB 3.0, dedicated iDRAC network port Video card: VGA Up to 13 x Gen3 slots, (3 x8 + 10 x16)
PowerEdge R940xa Up to four Intel® Xeon® Scalable processors, up to 28 colors each 48 DDR4 DIMM slots, Supports RDIMM /LRDIMM, up to 2666MT/s, 6TB max Up to 12 NVDIMMs, 384GB Max Supports registered ECC DDR4 DIMMs only Internal Controllers: PERC H730P, H740P, H330 Software RAID (SWRAID) S140 Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB or 240GB External PERC (RAID): H840 12Gbps SAS HBAs (non-RAID): External-12Gbps SAS HBA (non-RAID). Internal- HBA330 (non-RAID) Front drive bays: Up to 8x 2.5” SAS SATA (HDD/SSD) max 30TB, or up 24 x 2.5” SAS/SATA (HDD/SSD) max 92TB, or up to 32 SAS/SATA (HDD/SSD) with up to 4 NVME PCIe SSD max 132TB Network Daughter Card Options 4 x 1GE, 4 x 10GE, 2 x 10GE+2 x 1GE, or 2 x 25GE Front ports: Video, 2 x USB 2.0, 1 dedicated IDRAC Direct Micro-USB. (Optional 1 x USB 3.0 only offered on the 8-drive configuration). Rear ports: Video, serial, 2 x USB 3.0
Internal port: 1 x USB 3.0
Video card: VGA
PCIe: Up to 12 x Gen3 slots, (6×16 slots o

Dell EMC PowerEdge One Socket Tower Servers Technical Specifications

Single-socket (single CPU) tower servers provide a cost-effective entry-level solution for businesses migrating from PCs or laptops to servers. Designed for key office workloads such as file sharing, printing, point of sale and database applications.





Model Processor Memory Controllers Drive Bays Slots
PowerEdge T110 Quad-core Intel® Xeon® processor 3400 series Dual-core Intel® Celeron® G1101 Intel® Pentium® G6950 Dual-core Intel® Core® i3 processor 500 series Up to 16GB (4 DIMM slots): 1GB/2GB/4GB DDR3 up to 1333MHz Internal: PERC H200 (6Gb/s) SAS 6/iR PERC S100 (software based) PERC S300 (software based) External HBAs (non-RAID): 6Gbps SAS HBA LSI2032 PCIe SCSI HBA Up to four 3.5” SAS or SATA drives 4 PCIe G2 slots: Two x8 slots One x4 slot One x1 slot
PowerEdge T130 1 processor from the following product families: • Intel® Xeon® processor E3-1200 v6 product family • Intel Pentium® • Intel CoreTM i3 • Intel Celeron® Architecture: Up to 2400MT/s DDR4 DIMMs Memory type: UDIMMs Memory module sockets: 4
Maximum RAM: Up to 64GB
3.5″ Enterprise SATA 7.2k HDDs 3.5″ nearline SAS 7.2k HDDs 3.5″ 7.2k SATA entry drives 4 x 3.5″ cabled HDDs 1×8 PCIe 3.0 (x16 connector) 1×4 PCIe 3.0 (x8 connector) 1×4 PCIe 3.0 (x8 connector) 1×1 PCIe 3.0 (x1 connector)
PowerEdge T140 1 processor from the following: Intel® Xeon® E-2100 product family, Intel Pentium®, Intel Core i3®, Intel Celeron® 4x DDR4 DIMM slots, supports UDIMMs, speeds up to 2666MT/s, 64GB max. supports registered ECC. Internal controllers: PERC H730P, H330, HBA330 (non-RAID) Software RAID: PERC S140 External HBAs: 12Gbps SAS HBA (non-RAID) Boot Optimized Storage Subsystem: 2x M.2 240GB (RAID 1 or No RAID), 1x M .2 240GB (No RAID only) Up to 4 x 3.5" cabled bays Networking options: 2 X 1GbE LOM Front Ports: 1x USB 3.0, 1x iDRAC micro USB 2.0 management port Rear Ports: 2x USB 3.0, 4x USB 2.0, VGA, serial connector Internal USB: 1x internal USB 3.0 4 PCIe Slots:
1×8 Gen3 (x16 connector) FH/HL
1×8 Gen3 (x8 connector) FH/HL
1×4 Gen3 (x8 connector) FH/HL
1×1 Gen3 (x1 connector) FH/HL
PowerEdge T320 Intel® Xeon® processor E5-2400 product family Intel Xeon processor E5-1410 Intel Pentium® processor 1400 product family Up to 192GB (6 DIMM slots): 2GB / 4GB / 8GB / 16GB / 32GB DDR3 up to 1600MT / s ge1 Up to 32TB Choose from four 3.5" cabled, eight 3.5" hot-plug, or sixteen 2.5" hot-plug drive bays 5 PCIe slots: • One x16 slot with x16 bandwidth, 3.0, full-length, full-height • One x8 slot with x4 bandwidth, 3.0, half-length, full-height • One x8 slot with x4 bandwidth, 2.0, half- length, full-height • One x8 slot with x4 bandwidth, 3.0, full-length, full-height • One x8 slot with x1 bandwidth, 2.0, full-length, full-height
PowerEdge T330 1 processor from the following product families: • Intel® Xeon® processor E3-1200 v6 product family • Intel Pentium® • Intel CoreTM i3 • Intel Celeron® Architecture: Up to 2400MT/s DDR4 DIMMs Memory type: UDIMMs Memory module sockets: 4
Maximum RAM: Up to 64GB
• 2.5″ SATA 7.2k • 2.5″ SATA SSDs • 2.5″ nearline SAS 7.2k • 2.5″ SAS 10k HDDs • 2.5″ SAS 15K HDDs
• 3.5″ Enterprise SATA 7.2k HDDs
• 3.5″ nearline SAS 7.2k HDDs
8 x 3.5″ bays (also supports 2.5″ HDD in 3.5″ hybrid drive carrier) 1×8 PCIe 3.0 (x16 connector) 1×4 PCIe 3.0 (x8 connector) 1×4 PCIe 3.0 (x8 connector)
1×1 PCIe 3.0 (x1 connector)
PowerEdge T340 1 processor from the following: Intel® Xeon® E-2100 product family, Intel Pentium®, Intel Core i3®, Intel Celeron® 4x DDR4 DIMM slots, supports UDIMMs, speeds up to 2666MT/s, 64GB max. supports registered ECC. Internal controllers: PERC H730P, H330, HBA330 (non-RAID) Software RAID: PERC S140 External HBAs: 12Gbps SAS HBA (non-RAID) Boot Optimized Storage Subsystem: 2x M.2 240GB (RAID 1 or No RAID), 1x M .2 240GB (No RAID only) Up to 8 x 3.5” hot-pluggable bays (also supports 2.5” HDD in 3.5” hybrid drive carrier) Networking Options: 2 X 1GbE LOM Front Ports: 1x USB 3.0, 1x iDRAC micro USB 2.0 management port Rear Ports: 2x USB 3.0, 4x USB 2.0, VGA, serial connector Internal USB: 1x internal USB 3.0 4x PCIe Slots:
1×8 Gen3 (x16 connector) FH/HL
1×8 Gen3 (x8 connector) FH/HL
1×4 Gen3 (x8 connector) FH/HL
1×1 Gen3 (x1 connector) FH/HL

Dell EMC PowerEdge Two-Socket Tower Servers Technical Specifications

Two-socket (dual CPU) tower servers offer a wider range of features to accommodate high-performance applications such as web service, consolidation, and virtualization. They include more cache and speed, as well as flexibility for expansion and additional processors.



Model Processor Memory Controllers Drive Bays I / O & Ports
PowerEdge T420 Intel® Xeon® processor E5-2400 product family Up to 384GB (12 DIMM slots): 2GB / 4GB / 8GB / 16GB / 32GB DDR3 up to 1600MT / s Internal controllers: PERC S110 (SW RAID) PERC H310 PERC H710 PERC H710P Choose from four 3.5" cabled, eight 3.5" hot-plug, or sixteen 2.5" hot-plug drive bays 6 PCIe slots: • Two x16 slots with x16 bandwidth, 3.0, full-length, full-height • One x8 slot with x4 bandwidth, 3.0, half-length, full-height • One x8 slot with x4 bandwidth, 2.0, half- length, full-height • One x8 slot with x4 bandwidth, 3.0, full-length, full-height • One x8 slot with x1 bandwidth, 2.0, full-length, full-height
PowerEdge T430 Intel® Xeon® processor E5-2600 v4 product family Chipset: Intel C610 series chipset Processor sockets: 2 Internal interconnect: Two QPI links at 9.6 GT/s Cache: 2.5MB per core; core options: 4, 6, 8, 10, 12, 14 12 DIMM slots: 4GB/8GB/16GB/32GB DDR4 up to 2400MT/s Support for a maximum of 1 internal controller and 1 external controller PERC H730, PERC H730P and PERC H830   Support for up to 6 full height slots: 4 x PCIe 3.0, 2 x PCIe 2.0
PowerEdge T440 Up to two Intel® Xeon® Scalable processors, up to 14 colors per processor 16 DDR4 DIMM slots, Supports RDIMMs/LRDIMMs, speeds up to 2666MT/s, 1TB* max Supports registered ECC DDR4 DIMMs only Internal controllers: PERC H330, H730P, H740P, HBA330, Software RAID (SWRAID) S140 Boot Optimized Storage Subsystem: HWRAID 2 x M.2 120GB SSDs, 240GB External PERC (RAID): H840 External HBAs (non-RAID): 12 Gbps SAS HBA Up to 4 or 8 x 3.5” SAS/SATA (HDD/SSD) max 112TB or up to 16 x 2.5” SAS/SATA (HDD/SSD) max 61TB 2 x 1GbE LOM 1 dedicated iDRAC port 9 x USB (5 x USB 2.0, 4 x USB 3.0) 1 VGA video port and 1 serial port Up to 5 PCIe Gen3 slots
PowerEdge T620 Intel® Xeon® processor E5-2600 product family Up to 768GB (24 DIMM slots): 2GB / 4GB / 8GB / 16GB / 32GB DDR3 up to 1600MT / s Internal controllers: PERC S110 (RAID SW) PERC H310 PERC H710 PERC H710P External HBAs (RAID):
PERC H810
External HBAs (non-RAID):
6Gbps SAS HBA
Choose from eight 3.5" hot-plug drive bays plus four PCIe SSD drives (optional), twelve 3.5" hot-plug drive bays, sixteen 2.5" hot-plug drive bays plus four PCIe SSD drives (optional), or thirty-two 2.5 ” hot-plug drive bays 7 PCIe slots: • Four x16 slots with x16 bandwidth, full-length, full-height • Two x8 slots with x8 bandwidth, full-length, full-height • One x8 slot with x4 bandwidth, full-length, full-height
PowerEdge T630 Intel® Xeon® processor E5-2600 v4 product family Up to 1.5TB (24 DIMM slots): 2GB/4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P Internal HBA (Non-RAID): HBA330 External HBAs (RAID): PERC H830 Internal hard drive bay and hot-plug backplane: Up to 8 x 3.5″ SAS, SATA, nearline SAS, SSD, PCIe SSD drives with optional flex bay Up to 18 x 3.5″ SAS, SATA, nearline SAS, SSD drives Up to 16 x 2.5″ SAS, SATA, nearline SAS, SSD, PCIe SSD drives with
optional flex bay
Up to 32 x 2.5″ SAS, SATA, nearline SAS, SSD drives
8 PCIe slots: • Slot 1: one x16 PCIe 3.0 for FL/FH card from CPU1 • Slot 2: one x8 PCIe 2.0 for FL/FH card from PCH (x4 lanes) • Slot 3: one x16 PCIe 3.0 for FL/FH card from CPU1 • Slot 4: one x8 PCIe 3.0 for HL/FH card from CPU2 • Slot 5: one x8 PCIe 2.0 for FL/FH card from CPU2 (x4 lanes)
• Slot 6: one x16 PCIe 3.0 for FL/FH card from CPU2
• Slot 7: one x16 PCIe 3.0 for FL/FH card from CPU2
• Slot 8 (Internal PERC slot): one x8 PCIe 3.0 for HL/FH card from
CPU1
PowerEdge T640 Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 28 colors per processor 24 DDR4 DIMM slots, Supports RDIMMS/ LRDIMMS, speeds up to 2993MT/s, 3TB max Up to 12 NVDIMM, 192GB max Supports registered ECC DDR4 DIMMs only Internal controllers: PERC H330, H730P, H740P, HBA330, Software RAID (SWRAID) S140 Boot Optimized Storage Subsystem: HWRAID 2 x M.2 120GB SSDs, 240GB External PERC (RAID): H840 External HBAs (non-RAID): 12 Gbps SAS HBA Up to 8 or 18 x 3.5” SAS/SATA (HDD/SSD) max 216TB or up to 16 or 32 x 2.5” SAS/SATA (HDD/SSD) max 122TB or up to 16 x 2.5 SAS/SATA (HDD/SSD) ) + 8x NVMe SSD max 112TB 2 x 10GbE LOM (1GbE/10GbE) 8 x USB (1 x USB 2.0, 1 x USB 3.0, 6 x USB 2.0/3.0) dedicated IDRAC Direct Micro-USB Video card: VGA Up to 8 PCIe Gen3 slots

Dell EMC C-Series Blade Server Technical Specifications

Built for scale-out workloads like high-performance computing, deep learning, and data analysis, Dell EMC PowerEdge C-series platforms deliver the latest high-speed memory, fast NVMe storage, and workload-based BIOS tuning . Efficiently and predictably scale with flexible configurations and advanced connectivity options.



Model Processor Memory storage I / O & Ports
PowerEdge C4140 Two Intel® Xeon® Scalable processors, up to 20 colors per processor Up to 24 DDR4 DIMMs in total; Supports RDIMM /LRDIMM speeds up to 2666, 1.5TB Max ECC Registered DDR4 IDSDM or Internal M.2 Boot Module (2 x M.2) -120G or 240G (mirrored configuration) Four (4) Double Wide accelerator Gen3 x16 PCIe slots Two (2) low profile Gen3 x16 PCIe slots Front ports: Power button, System ID / Status LED, Health Status LED Rear ports: 2 USB 3.0 Port and iDRAC ethernet port
PowerEdge C6420 Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 205W and 28 colors per processor 8 DIMM slots per socket with max of 1024GB with options for 16GB/32GB/64GB RDIMMS @ 2933MT/s, 8GB RDIMMs @2666MT/s, and 128 LRDIMMs @2666MT/s. One 120/240GB M.2 SATA RI SSD boot drive or Two 120/240GB M.2 SATA RI SSD boot drives in RAID 1, One 16/32/64GB MicroSD card Controllers: S140 Software RAID with Intel C620 Chipset SATA controller (RAID 0, 1, 5, 10) Hardware RAID using PERC H330 Mezzanine (RAID 0, 1, 5, 10, 50), PERC H730p Mezzanine (RAID 0, 1, 5, 6, 10, 50, 60) Non RAID: HBA330 Mezzanine, 12Gbps SAS LP PCIe HBA Rear ports: 2 x USB 3.0 ports, 1 Micro USB port for iDRAC Direct One x16 PCIe Gen3 riser (low profile, half height and half length) One x8 PCIe Gen3 Mezzanine (for storage controller) One x16 PCIe Gen3 OCP Mezzanine (for network controller) One x16 PCIe Gen3 riser (for M.2 Boot Device)

Dell EMC M Series Servers Technical Specifications

Designed to lead the industry in quick and easy configuration and deployment, Dell M-Series blade servers feature modular I/O switches, plus two built-in 1Gb NICs for easy upgrades and a passive midplane that can handle 40Gb / s on four mezzanine doors per half-height slot. These features provide an easy and effective solution for scaling your I/O infrastructure, which can provide significant savings in time, cabling, and switch port costs.



Model

Processor

Memory

Storage Controllers

Drive Bays

Raid Controllers

I / O Slots

PowerEdge M610

Quad-core or six-core Intel® Xeon® processors 5500 and 5600 series

Up to 192GB (12 DIMM slots): 1GB / 2GB / 4GB / 8GB / 16GB ECC DDR3 up to 1333MHz

Hot-plug hard drive options: 2.5” SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K) Maximum internal storage: Up to 1.8TB per blade options

Two 2.5” SAS/Solid State hot-swappable drives



PowerEdge M610x

Quad-core or six-core Intel® Xeon® processors 5500 and 5600 series

Up to 192GB (12 DIMM slots): 1GB / 2GB / 4GB / 8GB / 16GB DDR3 up to 1333MT / s

Hot-plug hard drive options: 2.5” SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K) Solid state storage cards: Fusion-io® 160GB ioDrive PCIe solid state storage card Fusion-io 640GB ioDrive Duo PCIe solid state storage card Fusion-io 320GB ioDrive Mono PCIe solid state storage card Fusion-io 640GB ioDrive Mono PCIe solid state storage card Fusion-io 1.28TB ioDrive Mono PCIe solid state storage card

Two 2.5” SAS/Solid State hot-pluggable drives



PowerEdge M620

Intel® Xeon® processor E5-2600 and E5-2600 v2 product families

Up to 768GB (24 DIMM slots): 4GB/8GB/16GB/32GB DDR3 up to 1866MT/s Up to 1.5TB (24 DIMM slots): 64GB DDR3 LRDIMM up to 1600MT/s (with Intel Xeon processor E5-2600 v2 product family only)

Hot-plug hard drive options: Up to 2 x 2.5” Express Flash PCIe SSD, SATA HDD/SSD, or SAS HDD/SSD Maximum internal storage: Up to 2.4TB with 2 x 2.5” SAS (10K) 1.2TB hard drives



Fully populated mezzanine card slots and switch modules yield 3 redundant I/O fabrics per blade

PowerEdge M630

Intel® Xeon® processor E5-2600 v4 product family

Up to 1.5TB (24 DIMM slots): 4GB / 8GB / 16GB / 32GB / 64GB DDR4 up to 2400MT / s

Hot-plug hard drive options: PowerEdge Express Flash NVMe PCIe SSD, SATA HDD/SSD or SAS HDD/SSD 4 x 1.8″ SSD. 2 x 2.5″ PCIe SSDs



2 x PCIe 3.0 (x8) mezzanine cards

PowerEdge M640

Up to two Intel® Xeon® Scalable processors, up to 28 colors per processor

16 DDR4 DIMMs in total; Supports RDIMM / LRDIMM speeds up to 2666MT / s, 2TB Max ECC Registered DDR4

Internal controllers: Software RAID S140, PERC9 H330, H730P Internal Dual SD Module M.2 available for Boot Optimized Storage System (BOSS)

Front: Up to 2 x 2.5 ”SAS / SATA (HDD / SSD), NVMe SSD, max 12.8 TB



Network daughter card options 2 x 10GE + 4 x 1GE, 4 x 10GE Front ports: Power button System ID / Status LED 1 USB 2.0 MicroAB port with iDRAC management function 1 USB 3.0 port Rear ports: see enclosure specifications Video card: VGA controller integrated with iDRAC PCIe: See enclosure specifications

PowerEdge M710

Latest quad-core or six-Core Intel® Xeon® processors 5500 and 5600 series

18 DIMM slots 1GB/2GB/4GB/8GB/16GB ECC DDR3 Support for up to 192GB using 12 x 16GB DIMMs

Internal Hot-Swappable Drives: 2.5” SAS (10K RPM): 36GB, 73GB, 146GB, 300GB, 600GB 2.5” SAS (15K RPM): 36GB, 73GB 146GB Solid State Drives (SSD): 25GB, 50GB, 100GB, 150GB Maximum Internal Storage: Up to 1.2TB via 4 x 300GB SAS Hard Drives External Storage: Dell™ EqualLogic™ PS6000 Series PowerVault™ NX1950 Unified Storage Solution PowerVault™ MD3000i Disk Storage Options



Internal: PERC H200 Modular (6Gb/s) PERC H700 Modular (6Gb/s) with 512MB battery-backed cache; 512MB, 1GB Non-Volatile battery-backed cache SAS 6/iR Modular CERC 6/i Modular PERC 6/i Modular with 256MB battery-backed cache



PowerEdge M710HD

Quad-core or six-core Intel® Xeon® processors 5500 and 5600 series

Up to 288GB (18 DIMM slots): 1GB/2GB/4GB/8GB/16GB ECC DDR3 up to 1333MT/s

Hot-plug hard drive options: 2.5” SATA SSD, SAS (15K, 10K)



PERC H200 Integrated SAS Controller (6Gb/s)



PowerEdge M820

Intel® Xeon® processor E5-4600 product family

Up to 1.5TB (48 DIMM slots): 4GB/8GB/16GB/32GB DDR3 up to 1600MHz

Hot-plug hard drive options: Up to four 2.5” SAS, SSD, or up to two PCIe Express Flash SSD



Internal controllers: PERC H310 PERC H710 PERC H710P



PowerEdge M830

Intel® Xeon® processor E5-4600 v4 product family

Up to 3TB (48 DIMM slots): 4GB / 8GB / 16GB / 32GB / 64GB DDR4 up to 2400MT / s

Hot-plug hard drive options: PowerEdge Express Flash NVMe PCIe SSD, SATA HDD/SSD or SAS HDD/SSD 12 x 1.8″ SSD, 4 x 2.5″ SATA HDD/SSD or SAS HDD/SSD, 2 x 2.5″ PCIe SSD and 2 x 2.5″ SATA HDD/SSD or SAS HDD SSD



Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P



PowerEdge M905

Up to Six-Core AMD Opteron 8000 series processors

24 DIMM slots 1GB/2GB/4GB ECC DDR2 667/800MHz Options Support for up to 192GB1 using 24x8GB DIMMs



Two 2.5” Hot-Swappable SAS/Solid State Drives

SAS6/IR (Raid 0/1) hardware based CERC6/IR (Raid 0/1 w/ Cache) PERC 6i Modular (RAID 0/1 w/ battery-backed cache) PERC 6.2 Firmware



PowerEdge M910

Up to Four Intel® Xeon® 7500 series Quad-, Six-, or Eight-Core processors; or, Up to Two Intel® Xeon® 6500 series Quad-, Six-, or Eight-Core processors

1GB/2GB/4GB/8GB/16GB ECC DDR3 Support for up to 512GBs using 32 x 16GB DIMMs



Two 2.5” SAS/Solid State hot-swappable drives

PERC H200 Modular (6Gb/s) PERC H700 Modular (6Gb/s) with 512MB battery-backed cache; 512MB, 1GB Non-Volatile battery-backed cache



PowerEdge M915

AMD Opteron™ 6100, 6200 and 6300 series processors

Up to 1TB (32 DIMM slots): 1GB/2GB/4GB/8GB/16GB/32GB DDR3 up to 1333MT/s



Two 2.5” SAS/solid state hot-pluggable drives

PERC H200 Modular (6Gb/s) PERC H700 Modular (6Gb/s) with 512MB battery-backed cache



Dell EMC PowerEdge FX Series Technical Specifications

The FX architecture's innovative modular design supports IT resource building blocks of varying sizes (computing, storage, networking, and management) so data centers have greater flexibility in building their infrastructures.



Model Processor Memory Form Factor Controllers Primary Storage Drive Bays I / O & Ports
PowerEdge FC430 Intel® Xeon® processor E5-2600 v4 product family Processor sockets: 2 Cache: 2.5MB per core; color Up to 256GB (8 DIMM slots): 4GB / 8GB / 16GB / 32GB DDR4 up to 2400MT / s   Internal controllers: PERC S130 (SW RAID) Hot-plug hard drive options: Up to 2 x 1.8″ uSATA SSDs   Access to 1 x PCIe 3.0 (x8) expansion slots
PowerEdge FC640 Up to two Intel® 2nd generation Xeon® Scalable processors, up to 28 colors per processor 16 DDR4 DIMM slots, supports RDIMM / LRDIMM / AEP, up to 2933MT/s speeds, 2TB max mem ECC Registered DDR4   Internal controllers: Software RAID S140, PERC H330, H730P, HBA330 Boot Optimized Storage system, Internal Dual SD Module   Front: Up to 2 x 2.5 ”SAS / SATA (HDD / SDD), NVMe SSD on a Universal Backplane, max 12.8TB (PCIe SSD) Network daughter card options 2 x 10GE + 2 x 1GE, 4 x 10GE Video card: VGA controller integrated with iDRAC PCIe: See enclosure specifications
PowerEdge FC830 Intel® Xeon® processor E5-4600 v4 product family Processor sockets: 4 Cache: 2.5MB per core; core options: 4, 6, 8, 10, 12, 16, 18, 22 Chipset: Intel C610 series Up to 1.5TB (48 DIMM slots): 4GB / 8GB / 16GB / 32GB / 64GB DDR4 up to 2400MT / s   Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P Hot-plug hard drive options: PowerEdge Express Flash NVMe PCIe, SATA HDD/SSD or SAS HDD/SSD Up to 16 x 1.8″ SSD or 8 x 2.5″   Access to 4 x PCIe 3.0 (x8) expansion slots, (up to 8 for certain configurations)
PowerEdge FD332     Half-width – supports up to 16 small form factor 2.5” storage devices Up to 3 FD332 storage blocks per PowerEdge FX2 enclosure (configuration dependent) Internal Controllers: FD33xS (Single PERC), FD33xD (Dual PERC). Default is HBA mode; upgradeable to RAID mode via license. HBA330: FD332xS_HBA (Single), FD332xD_HBA (Dual)
PowerEdge FX2     2U       FX2s configuration: Up to 8 x PCIe 3.0 I/O expansion slots (low profile/half-length)

Dell EMC PowerEdge MX Series Technical Specifications

Integrated 7U modular solution designed for enterprise data center density with easy deployment, management and maximum longevity. The PowerEdge MX features industry-leading midplaneless design and scalable fabric architecture to support new processor technologies, new storage types, and new connectivity innovations in the future.



Model Processor Enclosure Memory Drive Bays Networking Options Controllers Front Ports
PowerEdge MX7000 Up to 6 3000W; PSU and grid redundancy support       Fabric options: Up to 2 pairs of redundant general-purpose switches or modular pass-through bays (Fabrics A and B); redundant pair of storage specific switch bays (Fabric C) Up to 25GbE, 32Gbps Fiber Channel, 12Gbps SAS   2 USB 2.0 Type A or KVM control (keyboard and mouse only) 1 USB 2.0 Type Micro-AB direct management port 1 Mini Display Port connector for video Front buttons/indicators: Power button System status LED
health icon
Ambient temperature icon
IOM icon
Fan icon
Stack/group icon
ID button
PowerEdge MX5016s   PowerEdge MX Chassis   Up to 16 x 2.5” SAS (HDDs/SSDs) in one storage sled. Up to 112 drives, 7 storage sleds within the PowerEdge MX chassis (plus 6 internal server storage drives).   HBA330 mini-mezz (MMZ)- (on the connected server) PERC H745P MX- (on the connected server)
PowerEdge MX740c One or two 2nd Generation Intel™ Xeon™ Scalable Processors, up to 28 colors per processor Intel® C628 Chipset with optional Intel® QuickAssist Technology   24 DIMM slots in total; supports DDR4 RDIMMs, LRDIMMs; up to 2933 MT/s speed, 1.5TB maximum (RDIMM), 3TB maximum (LRDIMM) Front: Up to 6 x 2.5 ”SAS / SATA (HDD / SDD) or NVMe PCIe SSD   Internal controllers: S140 Software RAID, HBA330 Internal SAS HBA, PERC H730P Adapter, PERC H745P Adapter, HBA330 mini-mezzanine SAS HBA Internal boot options: Choice of optional Boot Optimized Storage Solution (BOSS) (2 X M.2 SDDs) or Internal controllers Dual SD Module (IDSDM)
PowerEdge MX840c Two or four 2nd Generation Intel™ Xeon™ Scalable Processors, up to 28 colors per processor Intel® C628 Chipset with optional Intel® QuickAssist Technology   48 DIMM slots in total; supports DDR4 RDIMMs, LRDIMMs; up to 2933 MT/s speeds, 3TB maximum (RDIMM), 6TB maximum (LRDIMM) Front: Up to 8 x 2.5 ”SAS / SATA (HDD / SDD) or NVMe PCIe SSD   Internal controllers: S140 Software RAID, HBA330 Internal SAS HBA, PERC H730P Adapter, PERC H745P Adapter, HBA330 mini-mezzanine SAS HBA Internal boot options: Choice of optional Boot Optimized Storage Solution (BOSS) (2 X M.2 SDDs) or Internal controllers Dual SD Module (IDSDM)

Some segments we help



Third party maintenance for Dell End-of-Life (EOL) and Dell End-of-Service-Life (EOSL)



A DC Parts made an analysis on more than 250 customer contracts that use storage, servers, networks and tapes and showed us that 40-60% of the equipment of these customers operate beyond the end dates of support.

There are simple options for you to reduce your expenses and feel more confident about your IT infrastructure. When you choose a custom solution to extend the life of your IT equipment, you can make big savings.



How can we help:



We offer our customers a unique assessment to help analyze their OEM support contracts and understand exactly which devices can be supported in the most affordable way, without compromising their performance.



Dell server support



Support services DC Parts provide support for the Dell server. We work to combine the right approach with the right equipment to meet your Dell server support needs.

With a highly trained team of certified engineers ready to solve any problems with your Dell server, DC Parts is uniquely qualified to serve you. If you would like to speak with a representative about purchasing support on the Dell server, contact us.

A DC Parts helps companies of all sizes better manage their IT data centers by providing third-party support services to leading equipment manufacturers, including: IBMHPEnetapp, Oracle SunCisco and more.

With support DC Parts, we manage all your hardware, between the manufacturers through a link. Support from DC Parts offers flexible service level agreements, certified engineering support teams and dedicated customer service representatives.

Extend the life and value of your IT assets. Contact DC Parts Support immediately.

Contact DC Parts and we will help you better optimize your IT investment

Questions?

Call our product team at 011 3022-4694 or send an email to: contato@dcparts.com.br

Warranty:

All the hardware in the DC Parts is fully tested, guaranteed and comes with a 90-day warranty. Above all, we will support you before, during and after the sale.



Product Experience:

In other words, we know how important it is that you get the product you need to meet your needs. In addition, we have a sales team and agile logistics to make the shortest possible delivery times possible.

Sending proposals within 2 business days, experimenting with data centers and integrators and we always try to get the best price.

Do not hesitate to contact us with any questions about compatibility, condition or the best product available for your need.

Our website represents only a fraction of the pieces we work with. But you can contact your complete requirements or equipment lists.

Select currency
PENSalt
error: Content is protected !!
Open chat
Need help?
