Storage DELL EqualLogic PS4100XV – With warranty and technical service for installation or support.
A DC Parts is a distributor of new and refurbished DELL equipment and accessories. Our technology experts can help you select and configure the right DELL server solution for your specific data needs. Like all of our equipment, DELL storages are fully tested, so you can count on worry-free service for years to come. And should the need arise, our team of certified engineers are on hand to provide support for any issues you may have. If you would like to speak with a representative about DELL equipment offerings, please contact us.
Description of the DELL EqualLogic PS4100XV
Dell EqualLogic PS4100 Storage Arrays are designed to provide outstanding flexibility, performance and capacity for growing business requirements. The PS4100XV 3.5 offers up to 7,2TB using twelve 600GB 15K SAS drives in a 2U/3,5 configuration.
PS4110 Series arrays are based on a modular, virtualized storage architecture that allows you to purchase only the storage you need, when you need it. Sophisticated yet simple management features accelerate SAN configuration, and built-in intelligence features detect network connections, automatically create RAID sets, and conduct system health checks. All PS Series arrays work together to automatically manage data, load balance across resources, or seamlessly expand your storage pool when you add a new array. The PS4110 series includes fault-tolerant capabilities through the use of fully redundant and hot-swappable controllers, fan trays, power supplies and disk drives.
EOS: 10/10/2018
PS4100XV 3.5 ISCSI SAN TECHNICAL CHARACTERISTICS
| PS4100 SERIES FEATURES | PS4100XV 3.5 ISCSI SAN TECHNICAL CHARACTERISTICS |
|---|---|
| product settings | Cost-effective performance and capacity for your enterprise data center |
| Inventory controllers | Dual controllers with 4GB non-volatile memory per controller |
| network interfaces | Management network: 1x 100BASE-TX per controller; Interface Ports: 2 x 1000GBASE-T ports per controller |
| hard disk drives | 12x Hot Pluggable 3,5″ 15K SAS |
| drive capacities | 600GB 15K SAS 3,5″ |
| System capabilities | Up to 7,2 TB |
| host protocol | Any standards-compliant iSCSI initiator |
| Volumes | up to 256 |
| Snapshots | 128 per volume / up to 2.048 total per group |
| PS series volume connections per group | Up to 512 per pool/1024 per group |
| Supported OS and hypervisors | Microsoft Windows Server including Hyper-V, VMware ESX Server, Red Hat Enterprise Linux (RHEL), SUSE Enterprise Linux (SLES), Oracle Linux, Oracle Solaris, IBM AIX, HP-UX, Mac OS X, Citrix XenServer, Novell NetWare |
| RAID supported | RAID 5, RAID 6, RAID 10, RAID 50 |
| TCP network support | IPv4, Support IPv6 Core |
| expansion option | Can be combined with other EqualLogic PS Series arrays in the same SAN group online. A maximum of two (2) PS4x00 Arrays can be in a group |
| Reliability | Vertical door sharing. Redundant hot-swappable controllers, power supplies, cooling fans and hot-swappable disks. Individual disk drive slot power control. |
| cabinet monitoring system | Automatic configuration and use of spare parts; SMART; Automatic replacement of bad blocks; Auto-Stat Disk Monitoring System (ADMS) to monitor data integrity on disk drives |
| management interfaces | EqualLogic SAN Headquarters multi-group event and performance monitoring tool. Console Serial. Ability to set up a separate management network. SNMP, Telnet, SSH, HTTP, Web (SSL), Host Scripting. Support for multiple administrators. |
| Security | CHAP authentication; Access control for iSCSI; Access control for management interfaces, including RADIUS support |
| Notification Methods | SNMP traps, email, syslog |
| Physics | Height: 2U (3,41″) Width: 17,57″ Depth: 23,4″ Weight: 64,4 lbs |
| The ability to | Dual 700W power supplies. AC voltage: 100-240 VAC. 700W (maximum, total). Frequency: 50/60 Hz |
| Rack Support | ReadyRails II static rails for tool-free mounting in 4-post racks with square or round unthreaded holes or tool-mounting in 4-post racks with threaded holes. Dell VersaRails Sliding Rails for 4-Post and 2-Post Racks 1U/2U rail mounting brackets designed to allow PS arrays to be mounted in racks whose posts have round holes |
Some segments of the economy that we help
Some segments of the economy that we help
Third party maintenance for DELL End-of-Life (EOL) and DELL End-of-Service-Life (EOSL)
A DC Parts made an analysis on more than 250 customer contracts that use storage, servers, networks and tapes and showed us that 40-60% of the equipment of these customers operate beyond the end dates of support.
There are simple options for you to reduce your expenses and feel more confident about your IT infrastructure. When you choose a custom solution to extend the life of your IT equipment, you can make big savings.
Learn more at Dell Storage Support and Maintenance
How can we help:
We offer our customers a unique assessment to help analyze their OEM support contracts and understand exactly which devices can be supported in the most affordable way, without compromising their performance.
DELL storage leases
A DC Parts provides DELL storage rentals for a convenient and affordable solution to a variety of data center issues such as seasonal spikes and data center relocation. We work to match the right approach with the right equipment to properly meet your customized need for DELL Storage and Blade rentals. With a highly trained team of certified engineers ready to troubleshoot any problems, DC Parts is uniquely qualified to serve you. If you would like to speak with a representative about leasing DELL machines please contact contact with us.
DELL storage support
Support services DC Parts provide support for DELL equipment. We work to combine the right approach with the right equipment to meet your DELL equipment support needs. With a highly trained team of certified engineers ready to solve any problems with DELL equipment, the DC Parts is uniquely qualified to serve you. If you would like to speak with a representative about purchasing DELL equipment support, please contact us. THE DC Parts helps companies of all sizes better manage their IT data centers by providing third-party support services to leading equipment manufacturers, including: IBM, HPE, DELL EMC, NETAPP and much more. With support DC Parts, we manage all your hardware, between the manufacturers through a link. Support from DC Parts offers flexible service level agreements, certified engineering support teams and dedicated customer service representatives. Extend the life and value of your IT assets. contact support DC Parts immediately.
